Factory Customized Size Yjv32 4+1 Core 4*185+95 4X185+95mm2 Undergroud Armoured Copper Cable

China Factory Customized Size Yjv32 4+1 Core 4*185+95 4X185+95mm2 Undergroud Armoured Copper Cable  manufacture and supplier

Factory Customized Size Yjv32 4+1 Core 4*185+95 4X185+95mm2 Undergroud Armoured Copper Cable image

Get Latest Price Request a quote

You May Like

Product Details

Model NO.
YJV32 4+1 Ccore
Current
DC & AC
Insulation Material
XLPE
Sheath Material
PVC
Material Shape
Round Wire
Wire Core Material
Bare Copper Wire
Certification
ISO, CCC, CE, VDE
Model
Yjv32
Brand
Huadong
Product Name
4 Core Armoured Copper Cable
Rated Voltage
0.6/1kv
Armour
Swa(Steel Wire Armoured)
Size
4*185+95mm2
Standards
IEC,Ieca, BS, DIN,GB Ect
Transport Package
by Wooden Drum
Specification
by meters
Trademark
huadong
Origin
China
HS Code
8544492100
Production Capacity
15 Million Km/Year

Product Description

Product Description

Factory customized size YJV32 4+1 core 4*185+95 4×185+95mm2 undergroud armoured copper cable

Application
Steel wire armoured cable, commonly abbreviated as SWA, is a hard-wearing power cable designed for the supply of mains electricity. It is one of a number of armoured electrical cables – which include 11kV Cable and 33kV Cable – and is found in underground systems, power networks and cable ducting.

Cable Construction
1.Conductor : Compact stranded copper conductor,
2.Insulation : XLPE(cross-linked polyethylene) rated at 90 °C
3.Inner sheath :PVC
4.Armored :Galvanized Steel Wire.
5.Sheath : PVC or FR-PVC

Cross Section
Approx Overall Diameter
Approx Weight YJV32
Approx Weight YJLV32
No x mm2
mm
mm
Kg/Km
4×4+1×2.5
20.1
790.7
680.4
4×6+1×4
21.6
932.0
765.3
4×10+1×6
25.1
1364.3
1090.6
4×16+1×10
28.0
1752.8
1307.6
4×25+1×16
31.5
2324.5
1622.0
4×35+1×16
34.0
2803.7
1863.2
4×50+1×25
38.5
3792.9
2514.3
4×70+1×35
43.6
4963.7
3119.7
4×95+1×50
49.9
6816.7
4243.2
4×120+1×70
55.1
8281.3
5005.3
4×150+1×70
59.4
9688.9
5724.2
4×185+1×95
65.4
11862.2
6806.1
4×240+1×120
73.2
14725.3
8210.3
4×300+1×150
80.7
18739.1
10561.6
4×400+1×185
90.0
23541.3
12827.9

Company Profile

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables

FAQ

1.HOW CAN I GET A QUOTATION?
Pls send your inquiry to us with cable details,our sales manager will send you quotation within 12 hours

2.WHETHER THESE PRODUCTS QUALITY ASSURED?
Most of cables are certificated. Also,we have strict QC, all products are 100%testedbefore delivery. Quality is assured.

3.CAN YOU SEND A SAMPLE FOR US TO TEST?
If we have inventory and total amount is small, it’s free.

4.WAHT’S YOUR PAYMENT TERMS?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.




We are China Factory Customized Size Yjv32 4+1 Core 4*185+95 4X185+95mm2 Undergroud Armoured Copper Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
