Electric Wire Copper Clad Aluminum Wire Electrical Cables and Wires Optical Fiber CCA Wire

China Electric Wire Copper Clad Aluminum Wire Electrical Cables and Wires Optical Fiber CCA Wire  manufacture and supplier

Electric Wire Copper Clad Aluminum Wire Electrical Cables and Wires Optical Fiber CCA Wire image

Get Latest Price Request a quote

You May Like

Product Details

Model NO.
CCA
Application
Overhead, Heating, Underground, Electric Conduction Such as Motor, Transformer,etc
Conductor Material
Enameled CCA Wire
Sheath Material
Bare Conductor
Insulation Material
Enameled
Material Shape
Round Wire
Range of Application
LSOH
Certification
ISO9001, CE, CCC, RoHS
Brand
Eternal
Diameter
0.10-5.00mm
Copper Content by Weight
30%,40%,50%
Copper Content by Volume
10A,15A,20A
Material Status
Annealed
Thermal Class
130,155,180,200,220,240 Degree
Style
Insulated Wire
Color
Brown,Red,Golden All Color as Required
Transport Package
Wooden Drum or Steel Wooden Drum
Specification
10A, 15A, 20A
Trademark
Eternal
Origin
China
HS Code
8544110000
Production Capacity
300ton/Month

Product Description

Product Description

Description
This round enameled wire is made of pure aluminum with insulation. And the magnet wire is used for interchanging electrical energy with magnetic energy. The series is one of the hot-sale products.

Application
The enameled round aluminum wire is specially used for household appliances, transformer winding, and industrial motor winding.

Properties

  1. good thermal stability.
  2. excellent mechanical properties as low spring back and scratch resistance.
  3. excellent heat, cryogen, solvent resistance.
  4. uniformity of insulation, high breakdown voltage, etc.
 Specification

Product Model Insulation Type Thermal Class Wire Gauge AWG National Standard IEC Standard NEMA Standard Application
PEWA/155 Polyester 155ºC (F) 0.30-5.00mm (4.5-29) GB T 23312.4 MW 24-A Household appliance, Transformer
EIWA/180 Polyester-imide 180ºC (H) 0.30-5.00mm (4.5-29) GB T 23312.5 IEC 60317-15 MW 76-A
EI/AIWA/200 Polyester or Polyester-imide overcoated polyamide-imide 200ºC (C) 0.30-5.00mm (4.5-29) GB T 23312.7 IEC 60317-25
EI/AIWA/220 Polyester or Polyester-imide overcoated polyamide-imide 220ºC (C) 0.30-5.00mm (4.5-29) Enterprise standard MW 35-A Industry motor, Household appliance, Transformer

Manufacture Process

Workshop

FAQ

1. How can I get some samples?

A: We provide free sample and will courier to you by DHL, FEDEX, UPS, TNT, etc. swiftly according to your requirements.

2. Are samples free shipping?
  A: The freight charge should be paid by customer first. And then we will deduct it from the formal order.

3. How do you control the quality?

A:

  • QC department will control the quality during the full production process.
  • Inspector will inspect each item according to the order, inspection report will transfer to you before loading.
  • Any third party inspection will be accepted during the production or before loading, such as SGS, BV, etc.
  • After-sale dept will follow the order and pay high attention on the feedback from your side after all the products delivered. Any quality problem, we will arrange the technical personnel to solve and bear the corresponding customer losses..

4. What if the cable we need have some differences on specifications from yours?
  A: Any differences, we can design and produce according to your requests.

5. What’s the package of the goods?
A: Usually wooden or steel drum or coil, or according to your requirement

6. What’s the lead time?
A: usually 10-30 working days.

Welcome your inquiry and calling soon……
