Product Details

Model NO.

ESP Cable

Current

AC Cable

Insulation Material

Epr or XLPE

Sheath Material

Lead Sheathed

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO

Model

Qyeq

Brand

Huatong Cable

Rated Voltage

5kv

Cross Section

1AWG

Insulation

Epr

Sheath

Lead

Certificate

API

Conductor

Solid Copper

Insulation2

Rubber

Armored

Galvanized Steel Strip

Usage

Oil

Market

Middle East, America

Transport Package

Standard Export Drum

Specification

Enterprise standard

Trademark

RNE DA

Origin

Hebei, China (Mainland)

HS Code

85444921

Production Capacity

300km/Month

Product Description

Electric Submersible Oil Pump Power Price High Voltage ESP Flat Cables Suppliers

TOP TEN CABLE MANUFACTURER/EXPORTER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY

Product descripation

Product Introduction: This product is mainly used to provide power for ESP Cable conductor continuous working temperature is not more than 232C(450F)

Execution standard: API RP11S6 ,IEEE1018

Structural drawing:

Cable structure:

Type	Conductor specification			EPDM insulation		LEAD sheath		Finished size ≤		Weight kg/km
Type	AWG	Area mm2	Outer diameter mm	Thickness mm	Outer diameter mm	Thickness mm	Outer diameter mm	Thickness mm	Width mm	Weight kg/km
6EP5LDGF	6	13	4.12	1.9	7.92	1.0	9.92	14.14	35.22	1.97
4EP5LDGF	4	20	5.19	1.9	8.99	1.0	10.99	15.21	38.43	2.36
2EP5LDGF	2	33	6.54	1.9	10.34	1.0	12.34	16.56	42.48	2.93
1EP5LDGF	1	42	7.35	1.9	11.15	1.0	13.15	17.37	44.91	3.30

Test voltage of the finished product before leaving the factory

Rated voltage (KV)	Test voltage(KV)
3	DC 30/5min or AC 10KV/1min,no-breakdown
5	DC 35/5min or AC 13KV/1min,no-breakdown

Packing & Shipping

We are China Electric Submersible Oil Pump Power Price High Voltage Esp Flat Cables Suppliers manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
