DIN VDE 0812 250/250V Liyy Flexible PVC Control Signal Transmission Cable

DIN VDE 0812 250/250V Liyy Flexible PVC Control Signal Transmission Cable image

Get Latest Price Request a quote

Product Details

Model NO.

LIYY

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Brand

Huadong

Rated Voltage

250/250V

Amour

Non Armour

Core

2-48 Cores or Customized

Standard

DIN VDE 0812

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

DIN VDE 0812 LiYY Cable

Application
This cable can be used for signal transmission betweenelectronic devices, in computer systems or process controlunits.
Construction
Conductor Class 5 Fine Stranded Bare Copper
Insulation PVC (Polyvinyl chloride)
Outer Sheath PVC (Polyvinyl chloride)

Characteristics
Voltage Rating Uo/U250/250V
Temperature Rating
Fixed: -30ºC to +80ºC
Minimum Bending Radius
Fixed: 5 x overall diameter

Cable Parameter:

NO OF CORES	NOMINAL CROSS SECTIONAL AREA mm2	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
2	0.14	3.2	12
2	0.25	3.6	17
2	0.34	4.2	19
2	0.50	5.6	23
2	0.75	5.9	48
2	1	6	61
3	0.14	3.4	17
3	0.25	3.8	21
3	0.34	4.5	19
3	0.51	5.9	31
3	0.75	6	57
4	0.14	3.7	19
4	0.25	4.1	27
4	0.34	4.9	32
4	0.5	6.4	39
4	0.75	6.5	69
4	1	6.5	85
5	0.14	4	22
5	0.25	4.5	32
5	0.34	5.6	38
5	0.5	7	47
7	0.14	4.7	27
7	0.25	5.4	42
7	0.34	6.6	50
7	0.5	7.6	65
8	0.14	5.31	30
8	0.25	6.1	51
8	0.34	7.2	61
8	0.5	7.9	75
12	0.14	5.8	48
12	0.25	6.6	71
12	0.34	7.9	85
12	0.5	9.7	121

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China DIN VDE 0812 250/250V Liyy Flexible PVC Control Signal Transmission Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
