Des/Lvc-IEC 60502 Al XLPE 0.6/1kv ABC Cable Aluminum Aerial Bundle Cables

Des/Lvc-IEC 60502 Al XLPE 0.6/1kv ABC Cable Aluminum Aerial Bundle Cables image

Get Latest Price Request a quote

Product Details

Model NO.

ABC

Insulation Material

XLPE

Sheath Material

XLPE

Material Shape

Round Wire

Wire Core Material

Aluminium Conductor

Certification

VDE

Model

ABC Overhead Insulated Cable

Brand

Huadong

Product Name

Aerial Bundled ABC Cable

Rated Voltage

0.6/1kv

Cores

2-5 Cores

MOQ

1000m

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

DES/LVC-IEC 60502 AL XLPE 0.6/1kV ABC Cable Aluminum Aerial Bundle Cables

ABC Cable Aluminum Aerial Bundle Cables Application
The aerial bundled cables designed for overhead distribution lines have all conductors made of aluminium 1350 and insulated with XLPE. Can be used for fixed installation as overhead power lines up to 1000 V incl.
ABC Cable Aluminum Aerial Bundle Cables Strandard
DES/LVC/ABC Specification; IEC 60502

ABC Cable Aluminum Aerial Bundle Cables Construction

Conductor : H68 aluminium conductor and compacted circular stranded (RM).

Insulation : XLPE

Assemby : The cores shall be laid up with a left-hand lay

Number of Cores x Nominal Cross Section	Min. Breaking Load of Conductor Strand	Current Rating in the Air	Outer Diameter	Total Weight
mm^2	kN	A	mm	kg/km
4×25 RM	3.5	84	21.5	420
4×35 RM	4.9	104	23.9	550
4×120+1×25 RM	16.8	246	43.8	1800
4×185+1×25 RM	25.9	332	50.7	2700

1.You are manufacturer or trader ?

We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?

Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?

1) All raw materials we selected are the highest quality.

2) Professional and skillful workers care every details in handling the producing.

3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?

Yes,OEM & ODM order is warmly welcomed.

Our technical engineers can give you the professional suggestions.

5.Can I get the sample?

Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China Des/Lvc-IEC 60502 Al XLPE 0.6/1kv ABC Cable Aluminum Aerial Bundle Cables manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
