cUL Listed C-S-a Standard 12/2 AC90 14/2 AC90 14/3 AC90 Aluminum Armour Cable

Application

AC90 is a flexible interlocked aluminum armoured cable approved for use in open and concealed wiring in dry locations. This wire is a cost effective alternative to conduit wiring, eliminates the need for conduit, fittings and the labour associated with pulling in wire, threading, and forming conduit.

Construction

AC90 construction provides mechanical protection of electrical conductors, allowing for bending around corners and fishing through walls of existing construction.

AC90 solid copper conductor configurations consist of 2, 3, or 4 solid copper conductors in sizes 14, 12, or 10 AWG.

AC90 stranded copper conductors consist of 3 stranded copper conductor configurations in sizes 8 or 6 AWG.

Specification & Description

Armour Interlocking:    Aluminum Strip

Conductors:           Solid/Stranded Copper

Conductor:            RW90

Insulation:            XLPE

Cable Assembly:       Separate tape

Dry Temperature:      Rating 90°C (High) / -40°C (Low)

Bonding Conductor:    Solid/Stranded Bare Copper

Maximum Rating:      600V Voltage

Dear clients:

We would like to give you a short introduction about us.Since the first order from foreign countries in 2005,
now we Hebei Huatong Wires&Cables Group becomes the largest exporter of cable in China: our annual exporting volume exceeds $800million in 2020, taking up 70% of our whole sales. Our headquarter is in Tangshan city, Hebei Province, founded in 1993, covering around 220,000 squaremeters, around 2600 employes. Besides, we have built sub-factories in Tanzania, Cameroon, Kazakhstan, and Korea.
A plan to build a new one in Panama in under consideration now.

We always focus on the middle an high-level oversea markets. Our main market is USA,with annual exporting volume around $250million in 2020. We also have exported large quantity to Canada, Australia, Spain, Netherland, Vietnam, Chile, Nigeria, South Africa, Zambia, Kazakhstan, Singapore, Philippines, Peru, Colombia, Venezuela…etc. Quality of products is the spirit for a manufacturer. We spend more than $20million each year to the R&D centre. There are 148 staff in our R&D team, including many top experts in cables area. Our lab is CNAS approved, most of
the tests can be carried here. Now we have gained UL, cUL, CSA, CE, TUV, SABS, KEMA,VDE,CPR, MSHA, PSB, DNV.GL, ABS….certificates and many type test reports.

We warmly welcome your visit.




Welcome to inquiry us!

The largest cUL and C-S-A certifited cables manufacturer in China!
