cUL CSA Approved 14/2 14/3 12/2 Building Wire Nmd90 Cable

cUL CSA Approved 14/2 14/3 12/2 Building Wire Nmd90 Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NMD90

Application

Heating, Building

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Flat Wire

Range of Application

Conduit or Recognized Raceways for Services

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Voltage

300V

Usage

Building

Certificate

cUL and CSA

Package

Plastic and Wooden Drums

Transport Package

Coils and Drums

Specification

14AWG, 12AWG, 10AWG, 8AWG, 6AWG

Trademark

HT CABLES

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

The largest CUL UL cable expert manufacturer in China

First factory in NMD90, TECK90, RPV90 mass production factory

Annual Export amount more than $500million, Yearly manufacturing capacity 5 Billion RMB.

Cable solutions to your particular requirements
Strict quality control system.
Strong technical support (technical data, drawing, etc.)
Free sample is available with economic express fee.

A P P L I C A T I O N S

NMD90 cables may be used for both exposed work in dry locations or concealed work in dry or damp locations.

The maximum allowable conductor temperature is 90°C. The minimum recommended installation temperature is -25°C for two-conductor cables and -10°C for three-conductor cables (with suitable handling procedures). Material should be properly stored above 0°C for 24 hours prior to installation. The maximum voltage rating for all intended applications is 300 volts. Consult the Canadian Electrical Code1 for further

information related to applications.

CONSTRUCTION

Canada standard C22.2 No. 48 (non-metallic sheathed cable)

Canadian Electrical Code1

NMD90 cables are available as two- or three-conductor cables with a bare grounding conductor. It is

manufactured using annealed (soft) copper conductors-compressed standing for stranded conductors; a

heat-resistant thermoplastic polyvinyl chloride (PVC) insulation and nylon jacket for the individual conductors with a PVC jacket for the overall construction.

SPECIFICATION

Conductor			Insulation		Ground		Approx. Jacket thickness		Approx. Cable Dia.		Approx. Cable weight		Allowable Ampacities 30°C
Size (AWG)	Cores	Strands	Inches	mm	Size (AWG)	Core	Inches	mm	Inches	mm	Ib/ 1000ft	Kg/ km
14	2	1	0.034	0.86	14	1	0.030	0.76	0.388*0.192	9.86*4.88	68	101	25*
14	2	1	0.034	0.86	14	1	0.030	0.76	0.388 x 0.192	9.86 x 4.88	68	101	25*
12	2	1	0.034	0.86	14	1	0.030	0.76	0.422 x 0.209	10.71 x 5.30	86	129	30*
10	2	1	0.034	0.86	12	1	0.030	0.76	0.481 x 0.230	12.21 x 5.84	122	182	40*
8	2	7	0.040	1.02	10	1	0.045	1.14	0.636 x 0.312	16.15 x 7.92	208	310	55
6	2	7	0.051	1.30	8	7	0.045	1.14	0.792 x 0.370	20.12 x 9.40	315	468	75
14	3	1	0.034	0.86	14	1	0.030	0.76	0.345	8.77	86	128	25*
12	3	1	0.034	0.86	14	1	0.030	0.76	0.381	9.69	114	169	30*
10	3	1	0.034	0.86	12	1	0.030	0.76	0.427	10.85	163	242	40*
8	3	7	0.040	1.02	10	1	0.045	1.14	0.570	14.47	275	408	55
6	3	7	0.051	1.30	8	7	0.045	1.14	0.695	17.65	421	627	75
3	3	7	0.051	1.30	6	7	0.080	2.03	0.925	23.48	799	1189	115

We are China cUL CSA Approved 14/2 14/3 12/2 Building Wire Nmd90 Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
