cUL Certified AC90 12/2 Armoured Electrical Cable
cUL Certified AC90 12/2 Armoured Electrical Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Applications:
For exposed and concealed wiring in dry, locations
For use in ventilated, non-ventilated and ladder-type cable trays in dry locations
Rated at 90°C dry
Standard:
CSA C22.2 No.51-14 Armoured Cables
CSA C22.2 No. 2256 Wire and Cable Test Methods
CSA C22.2 No. 0.3 Test Methods for Electrical Wires and Cables
FT4 – Flame Test- Vertical Tray Flame Test
Structure:
Conductor: solid or stranded copper
Insulation: Cross-linked Polyethylene (XLPE) Type RW90
Bonding Conductor (Ground): bare solid or stranded copper conductor
Cable Assembly: Kraft Paper Wrap
Armour: Galvanized steel armour or AlA armour
Prints on Cable:
HT CABLES c(UL) E466697 12AWG 2C + 14AWG TYPE AC90 600V TYPE RW90 INSULATED CONDUCTOR
2022/01
|
Size |
Conducto r type |
Groundin g conductor |
Insulation thickness |
Approx. Armour O.D. |
Approx. Weight |
Reel length |
|
AWG |
– |
AWG |
mm |
mm |
Kg/km |
m |
|
14-2 |
Solid |
14 |
0.76 |
12 |
170 |
150/75 |
|
14-3 |
Solid |
14 |
0.76 |
12.5 |
200 |
150/75 |
|
12-2 |
Solid |
14 |
0.76 |
12.8 |
203 |
150/75 |
|
12-3 |
Solid |
14 |
0.76 |
13.4 |
245 |
150/75 |
|
10-2 |
Solid |
12 |
0.76 |
14 |
261 |
150/75 |
|
10-3 |
Solid |
12 |
0.76 |
14.6 |
324 |
150/75 |
We are China cUL Certified AC90 12/2 Armoured Electrical Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
