CSA Rpv/Rpvu Solar Cable Electric/Electrical Wire 2kv

CSA Rpv/Rpvu Solar Cable Electric/Electrical Wire 2kv image

Get Latest Price Request a quote

Product Details

Model NO.

RPVU RPV

Current

AC Cable

Insulation Material

XLPE

Sheath Material

None

Material Shape

Round Wire

Wire Core Material

Copper ,Aluminum Alloy Conductor

Model

Brand

Renda

Product Name

Solar Cable

Standard

UL 4703 CSA

Conductor

Copper or Aluminum Alloy Conductor

Package

Soft Package

Price

Factory Price

Rated Voltage

600V 1000V 2kv

Size

12AWG 10AWG 8AWG 6AWG 4AWG

Insulation

Xlpo

Applicant

Photovoltaic System

Sample

Free

Transport Package

Soft Package

Specification

14 AGW 12AWG 10AWG 8AWG.

Trademark

RNE DA

Origin

China

HS Code

8544492100

Production Capacity

5000km/Month

Product Description

CSA / CUL listed 1000V 2KV 10awg 12awg RPV RPVU solar PV wire cable for photovoltaic system

Application:
RPVU RPV cables may be installed indoors or outdoors, in raceways and conduits, both above and below ground, and may be direct buried. Direct buried installations must comply with CE Code Rules 12-012 and 4-004. They are 90ºC, 2 kV rated, and suitable for use in a photovoltaic system.

Type RPVU RPV cables are for use on the DC and AC side of a photovoltaic system, suitable for installation in both wet and dry locations, and may be exposed to sunlight.

RPVU cables are RoHS Compliant.

Structure:
Aluminum:
• sizes from #6 AWG to 1000 kcmil, stranded
• compact stranded AA-8000 series aluminum conductor material (ACM) per ASTM B801 Class B or ASTM B836
Copper:
• sizes from #14 AWG to 1000 kcmil, solid or stranded
• bare, stranded annealed per ASTM B8 Class B compressed

Standard:
• CSA C22.2 No. 38 – Thermoset-Insulated Wires and Cables
• CSA C22.2 No. 271-11
• ASTM B3, B8, B787

UL File No.:
E365883

Voltage:
1000V/2000V

Working temperature:
90ºC MAX, -40ºC MIN

Performance:
• Deformation-resistant at high temperatures
• Excellent moisture resistance, exceeds UL 44
• Stable electrical properties over a broad temperature range
• Increased flexibility
• Resistant to crush and compression cuts
• UV/sunlight-resistant

Printing:
HUATONG CABLES CSA E365883 RPVU **AWG(***mm2) 2000V CU/XLPE 90C DRY OR WET (-40C) FT1 DIR BUR SUN RES ****M

Technical data:

Size (AWG/Kcmil)	Conductor		Insulation Thickness	Approx O.D.	Weight/Km	Weight/Km	Max. DC resistance at 20 C )	Max. DC resistance at 20 C )
Size (AWG/Kcmil)	Nos of strands(CU)	Nos of strands(AL)	mm	mm	kgs(CU)	kgs(AL)	Ω/km(CU)	Ω/km(AL)
14	7	/	1.52	4.9	35	/	8.62	14.1
12	7	/	1.52	5.3	48	46	5.43	8.88
10	7	/	1.52	5.9	69	56	3.409	5.589
8	7	7	2.03	7.7	112	80	2.144	3.515
6	7	7	2.03	8.7	160	102	1.348	2.211
4	7	7	2.03	9.9	244	135	0.8481	1.390
2	7	7	2.03	11.4	362	183	0.5335	0.8745
1/0	19	18	2.41	14.2	576	286	0.3354	0.5498
2/0	19	18	2.41	15.4	716	337	0.2660	0.4361
3/0	19	19	2.41	16.5	876	400	0.2110	0.3459
4/0	19	19	2.41	18.0	1073	477	0.1673	0.2743
250	37	36	2.79	20.1	1321	579	0.1416	0.2322
350	37	36	2.79	22.7	1753	750	0.1011	0.1659
400	37	36	2.79	23.7	2039	836	0.08851	0.1450
500	37	36	2.79	26.0	2520	1028	0.07080	0.1161
750	61	58	3.18	31.3	3745	1463	0.04721	0.07738

Certificate:
We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS,NF, AS/NZS CSA GOST and so on.we have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,KEMA, TUV, Bureau Veritas, Lloyd,IEC,GL,SA,NK,KR certificates.

Package:

We are China CSA Rpv/Rpvu Solar Cable Electric/Electrical Wire 2kv manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
