CSA List 3 Conductor 6 Gauge Nmwu Underground Black Electric Wire Copper Conductor 300V 75m Spool

CSA List 3 Conductor 6 Gauge Nmwu Underground Black Electric Wire Copper Conductor 300V 75m Spool image

Get Latest Price Request a quote

Product Details

Model NO.

14/2 - 6/3 AWG

Application

Building Wire

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Flat Wire

Range of Application

Building Wire

Certification

ISO9001, CE, CCC, RoHS, VDE, cUL CSA Certificate

Brand

Rne Da

Production Name

Nmd90 Cable

Voltage

300V

Size

14-2 14-3 12-2 12-3 10-3 10-2 AWG

Core

2+1, 3+1

out Sheathed Material

PVC

Outsheathed Color

White, Orange, Red, Black

Transport Package

Standard Export Drum

Specification

14awg 12awg 10awg 8awg 6awg

Trademark

RNE DA

Origin

Tangshan, Hebei Province

HS Code

8544492100

Production Capacity

300km/Month

Product Description

CUL and CSA Certification NMWU Cable Canada

Application:

NWMU cables may be used for underground installations, including direct burial. It may also be used for environments exposed to the weather in dry and wet locations. The maximum allowable conductor temperature is 60°C. The minimum recommended installation temperature is -40°C for two-conductor cables (sizes AWG 14 to AWG 6) and -25°C for all other sizes. Material should be properly stored above 0°C for 24 hours prior to installation.

Structure:

Conductor:         Annealed copper conductors with compressed standing for stranded conductors

Grounding Conductor :  Annealed bare copper conductors

Insulation:                      Cross-linked Polyethylene (XLPE)  or Polyvinyl chloride (PVC) and Nylon

Jacket:                            Polyvinyl Chloride (PVC), black

Conductor Colors:          white and black (for 2 conductor cables); white, black and red (for 3

conductor cables)

Standard:

CSA C22.2 No. 48 (non-metallic sheathed cable)

Technical data:

Conductor				Grounding Wire		Jacket Thickness	Cable Dimensions	Weight	Max. DC resistance at 20C
Size AWG	NO.	No. of strands	Insulation Thickness	Size ( AWG)	No. of Strands	Jacket Thickness	Cable Dimensions	Weight	Max. DC resistance at 20C
Size AWG	NO.	No. of strands	mm	Size ( AWG)	No. of Strands	mm	mm	kg/km	(Ω/km)
14	2	1	1.52	14	1	0.76	6.3 × 12.7	142	8.62
12	2	1	1.52	14	1	0.76	6.8 × 13.6	173	5.43
10	2	1	1.52	12	1	0.76	7.3 × 15.1	234	3.41
8	2	7	1.90	10	1	1.14	9.9 × 20.0	402	2.14
6	2	7	2.29	8	7	1.14	11.6 × 23.5	565	1.35
14	3	1	1.52	14	1	0.76	11.9	181	8.62
12	3	1	1.52	14	1	0.76	12.8	227	5.43
10	3	1	1.52	12	1	0.76	13.9	306	3.41
8	3	7	1.90	10	1	1.14	18.6	523	2.14
6	3	7	2.29	10	7	1.14	22.3	752	1.35

All dimensions are nominal and subject to normal manufacturing tolerances

Detail showing

Packing
Our cables are packed in standard package that fit for long distance road transportation

and shipping. We ensure our customers can receive the undamaged cables in good condition.

Company profile Certification Whorkshop First class testing equipment

FAQ

1).When can I get the price?

We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price,please call us ortell us in your e-mail so that we will regard your inquiry priority.

(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.

(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account or prepay us if you do not have an account.

(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
