CSA Certified Acwu90 Cable Metal Clad Armored with Aluminium Alloy Conductor

CSA Certified Acwu90 Cable Metal Clad Armored with Aluminium Alloy Conductor image

Get Latest Price Request a quote

Product Details

Model NO.

ACWU90

Application

Underground

Conductor Material

Aluminum

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Certification

ISO9001, CE, CCC, RoHS, cUL CSA

Brand

Huatong

Conductor

RW90

Core

3+1

Armor

Aluminum Alloy

Rated Voltage

600V 1000V

Standard

C-S-a C22 No. 131

Products Name

Acwu90

Market

The Us, Canada, Australia Ect

Certificate

cUL CSA

Shield

with or Without

Transport Package

Steel-Wooden Drum, Steel Drum

Specification

8AWG TO 1000MCM

Trademark

Hebei Huatong

Origin

China

HS Code

8544492100

Production Capacity

1000m/Month

Packaging & Delivery

Package Size

111.00cm * 111.00cm * 111.00cm

Package Gross Weight

111.000kg

Product Description

PVC sheath Metal-clad ACWU90 Cable for Canada

Application:

For open and concealed wiring in dry locations only.For use in cabletroughs and ventilated flexible cable ways in dry locations only. Minimum recommended installation temperature minus 40°C (with suitable handling procedures).Maximum conductor temperature 90°C. Approved for use with ceiling fixtures.Armoured cable for commercial, industrial and apartment use

Structure:

Conductor: Copper conductor with Copper grounding wire 14AWG to 2AWG

or aluminium alloy 8000series ACM with AL grounding wire 6AWG to 750MCM

Insulation: cross-linked polyethylene insulation (RW90 XLPE
Assemble wrap: Conductor assembly paper wrapped
Armored : bare interlocked aluminum armor.

5. Sheath: PVC Sheath

6. Number of conductor: Two, three or four core round laid

Standard: National : CSA C22.2 N° 2556; CSA C22.2 N° 51

UL File No.: E466697

Voltage:600V

Phase Conductor		Bonding Conductor	Phase conductor single wire numbers	Nominal thickness of XLPE insulation	Approx. diameter after assembly	Nominal thickness of inner sheath	Approx. Diameter armoured	Nominal thickness of outer sheath	Approx. O.D. of cable
Core	AWG or Kcmil	AWG or Kcmil	Nos.	mm	mm	mm	mm	mm	mm
3	14	14	7	0.76	7.3	1.14	14.7	1	17
3	12	14	7	0.76	8.3	1.14	15.7	1	18
3	10	12	7	0.76	9.7	1.14	17	1	19
3	8	10	7	1.14	12.3	1.52	20.4	1	22
3	6	8	7	1.14	14.2	1.52	22.3	1	24
3	4	8	7	1.14	16.6	1.52	24.8	1	27
3	3	6	7	1.14	17.9	2.03	27.1	1	29
3	2	6	7	1.14	19.6	2.03	28.8	1	31
3	1	6	19	1.4	22.4	2.03	31.6	1	34
3	1/0	6	19	1.4	24.5	2.03	33.6	1	36
3	2/0	6	19	1.4	26.7	2.03	35.8	1	38
3	3/0	4	19	1.4	29.2	2.03	38.4	1.2	41
3	4/0	4	19	1.4	32.1	2.03	41.3	1.2	44
3	250	4	37	1.65	35.7	2.03	44.8	1.2	47
3	300	4	37	1.65	38.4	2.79	49.1	1.2	51
3	350	3	37	1.65	40.9	2.79	51.6	1.2	54
3	400	3	37	1.65	43.3	2.79	54	1.2	56
3	450	3	37	1.65	45.5	2.79	56.2	1.2	59
3	500	3	37	1.65	47.5	2.79	58.2	1.5	61
3	550	3	37	2.03	51.3	2.79	62	1.5	65
3	600	2	61	2.03	53.4	2.79	64.1	1.5	67
3	650	2	61	2.03	55.1	2.79	65.8	1.5	69
3	700	2	61	2.03	56.9	2.79	67.6	1.5	71
3	750	2	61	2.03	58.6	2.79	69.3	1.5	72

We are China CSA Certified Acwu90 Cable Metal Clad Armored with Aluminium Alloy Conductor manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
