Copper Tape Screened Tinned Copper Wire Braided EMC 2yslcy VSD Variable Frequency Drive (VFD) Cable

Copper Tape Screened Tinned Copper Wire Braided EMC 2yslcy VSD Variable Frequency Drive (VFD) Cable image

Get Latest Price Request a quote

Product Details

Model NO.

2YSLCY

Current

DC & AC

Insulation Material

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper

Certification

VDE

Brand

Huadong

Rated Voltage

0.6/1kv

Size

1.5-240mm2

Cores

4 Cores or 3+3 Cores

Standard

DIN VDE 0250

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Copper tape Screened Tinned Copper Wire Braided EMC 2YSLCY VSD Variable Frequency Drive (VFD) Cable

Application
The cable has been developed for connecting motors to inverse rectifiers under consideration of EMC (electromagnetic
compatibility) requirements. It may be used under medium mechanical stress for fixed installations and temporary movement. This cable offers a good resistance against oil and grease. Suitable for outdoor installation but not direct burial.

Voltage Rating Uo/U0.6/1kV
Temperature Rating
Fixed: -30°C to +70°C
Flexed: -5°C to +70°C
Minimum Bending Radius
Fixed: 10 x overall diameter
Flexed: 25 x overall diameter

Construction

Conductor Class 5 flexible copper conductor

Insulation PE (Polyethylene)

Screen Aluminium-Foil

Braid TCWB (Tinned Copper Wire Braid)

Sheath PVC (Polyvinyl Chloride)

Cable Parameters

NO. OF CORES	NOMINAL CROSS SECTIONAL AREA mm²		NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
NO. OF CORES	Power Conductor	Earth Conductor	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
3 + 3 earth	1.5	0.25	10.2	140
3 + 3 earth	2.5	0.5	11.4	220
3 + 3 earth	4	0.75	13.1	323
3 + 3 earth	6	1	14.9	420
3 + 3 earth	10	1.5	18.4	615
3 + 3 earth	16	2.5	21.6	819
3 + 3 earth	25	4	25.3	1402
3 + 3 earth	35	6	27.8	1718
3 + 3 earth	50	10	32.6	2399
3 + 3 earth	70	10	38.9	3173
3 + 3 earth	95	16	44.3	4162
3 + 3 earth	120	16	46.8	5253
3 + 3 earth	150	25	53.5	6128
3 + 3 earth	185	35	59.5	7450
3 + 3 earth	240	50	70	10800
4	1.5	–	10.4	154
4	2.5	–	12.3	229
4	4	–	14.5	339
4	6	–	16.8	451
4	10	–	19.7	667
4	16	–	22	892
4	25	–	27	1441
4	35	–	30.3	1861
4	50	–	35	2547
4	70	–	39.4	3404
4	95	–	46	4888
4	120	–	51.4	5703
4	150	–	58.8	7040
4	185	–	61.1	9450
4	240	–	70	12500
