Copper Rubber Welding Cable

Copper Rubber Welding Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Welding cable

Application

Heating, Underground, Construction

Conductor Material

Copper

Sheath Material

None

Insulation Material

Rubber

Material Shape

Round Wire

Range of Application

Conduit or Recognized Raceways for Services

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Rated Voltage

Low Voltage 600V

Standard

UL1276

Transport Package

Coils and Drums

Specification

14awg-1000mcm

Trademark

Renda

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

Specifications:

Hebei Huatong 10 awg electric rubber welding cable

Advantages of Hebei Huatong Cables Group:
Top ten cable manufacturer in China
Largest manufacturer&exporter of UL listed cables in China
Annual export volume exceed USD300million
UL, CUL, CSA, TUV, KEMA, CE, BV, PSB, SABS, LLOYD’S, GL, NK, KR, ABS certificates
CNAS approved lab!

Welding Wire Applications:

Secondary voltage resistance welding leads
Temporary power supply applications not exceeding 600 volts A.C.
Battery Cable
Welding

•Use and installation

Designed as secondary voltage resistance welding cable leads, Battery cables, Temporary power uses, Power supply applications not exceeding 600V AC.

•Structure

CONDUCTOR: 6 AWG- 500Kcmil Stranded bare copper flexible, fully annealed, Class K, Bare-copper.
INSULATION: Ethylene Propylene Diene Monomer EPDM
COLOR: Black
PHYSICAL PROPERTIES:
TEMPERATURE RANGE: -40°C to 90°C Dry, 90°C Wet Oil and Water Resistant Non-Marking Jacket,
Lightweight & Very Flexible at Low Temp.
ELECTRICAL PROPERTIES:
VOLTAGE RATING: 600V rms, Maximum
INDUSTRY APPROVALS: ASTM B-172, National Electrical Code 630, ROHS
Features:
• EPDM insulation provides outstanding cut, abrasion and slag resistance
• Resistant to oil, chemicals, water, ozone, & solvents
• Red & black jacket
• Other colors available upon request*
