Copper, Aluminum Alloy Conductor cUL 14 Agw 12AWG 10AWG 8AWG Solar Power Cable Wire

Copper, Aluminum Alloy Conductor cUL 14 Agw 12AWG 10AWG 8AWG Solar Power Cable Wire image

Get Latest Price Request a quote

Product Details

Model NO.

RPVU90 cable

Current

DC Cable

Insulation Material

Xlpo

Sheath Material

Xlpo

Material Shape

Round Wire

Wire Core Material

Copper ,Aluminum Alloy Conductor

Certification

cUL

Model

Brand

Rneda

Products Name

PV Wire/PV Cable

Standard

UL 4703 Standard, CSA

Conductor

Copper or Aluminum Alloy Conductor

Package

Soft Package

Price

Wholesale Price

Certificate

UL cUL

UV Resistance

Yes

Usage

Solar Energy System

Type

Solar Power Plant

Lifelong

25 Years

Quality

High Performance

Transport Package

Soft Package

Specification

14 AGW 12AWG 10AWG 8AWG

Trademark

Huatong

Origin

China

HS Code

8544601200

Production Capacity

1800000

Product Description

Applications:

For exposed wiring and raceways for interconnection of solar photovoltaic systems as per CEC Part I Section 64-210

For exposed wiring and raceways (including Tray Cable as per CEC Part I Section 64-210) in wet and dry locations.

For direct earth burial (with protection as required by inspection)

Minimum recommended installation temperature of minus 40°C with proper handling procedures

Cables marked SUN RES for outdoor use and exposed wiring subjected to the weather

Specifications and Compliance:

CSA C22.2 No. 38 Thermoset-Insulated Wires and Cables
CSA C22.2 No. 271 Photovoltaic cables
-40°C Cold Bend and -40°C Cold Impact
Sunlight Resistant SUN RES, DIR BUR

Other Standards:
Underwriters Laboratories Standards UL-4703, UL-854, UL-44
UL 1685-FT4/IEEE 1202 (70,000 Btu/hr) Flame Test (1/0 AWG and larger)
ICEA T-29-520 (210,000 Btu/hr) Flame Test
NEMA WC70/ICEA S-95-658
NFPA 70: National Electrical Code (NEC)

Construction

Conductors:
Stranded conductors, uncoated copper per ASTM-B787 and ASTM-B8

Insulation:Cross-linked Polyethylene (XLPE) Type RPVU90

Features:
Available in 600V and 1000V/2000V. All cables comply with VW-1 (Vertical Wire) Flame Test. Insulation compounds are rated for flame and sunlight-resistance in all sizes and colors.

Photovoltaic conductors of 1/0 through 1000 KCMIL are rated for CT use. Sequential foot markings located every foot on master reels only for 1 AWG through 1000 KCMIL unless otherwise specified. RoHS compliant. Flexibility at Low Temperature Test. Carries -40 °C rating.

		Insulation Thickness XLPO mm		Outside Diameter mm		Allowable Ampacity(Amps)		Approximate Net Weight(lbs/1000 ft)
Number of
Strands
SizeAWG	600V	1000V	600V	1000V	600V	1000V	600V	1000V	600V	1000V
SizeAWG	600V	2000V	600V	2000V	600V	2000V	600V	2000V	600V	2000V
14	19	19	0.06	0.075	4.89	5.61	25	25	24	28
12	19	19	0.06	0.075	5.37	6.05	30	30	33	38
10	19	19	0.06	0.075	5.99	6.6	40	40	47	52
8	7*	7*	0.075	0.085	7.52	7.95	55	55	74	78
6	7*	7*	0.075	0.085	8.48	8.86	75	75	108	113
4	7*	7*	0.075	0.085	9.7	10.06	95	95	161	166
3	7*	7*	0.075	0.085	10.41	10.77	110	110	197	203
2	7*	7*	0.075	0.085	11.23	11.58	130	130	243	249
1	19	19	0.095	0.105	13.16	13.49	150	150	313	320
1/0	19	19	0.095	0.105	13.97	14.48	170	170	380	389
2/0	19	19	0.095	0.105	15.09	15.6	195	195	476	484
3/0	19	19	0.095	0.105	16.36	16.87	225	225	590	599
4/0	19	19	0.095	0.105	17.78	18.29	260	260	732	742
250	37	37	0.11	0.12	19.35	19.86	290	290	873	884
300	37	37	0.11	0.12	20.67	21.18	320	320	1035	1047
350	37	37	0.11	0.12	21.87	22.38	350	350	1198	1210
400	37	37	0.11	0.12	22.99	23.5	380	380	1358	1371
500	37	37	0.11	0.12	25.04	25.55	430	430	1680	1694
600	61	61	0.125	0.135	29.03	29.54	475	475	2057	2073
750	61	61	0.125	0.135	31.7	32.21	535	535	2508	2525
1000	61	61	0.125	0.135	35.61	36.12	615	615	3303	3322
