Class 5 Flexible Plain Copper PVC Insulation PUR (Polyurethane) Sheath PUR-Jz Control Cable

Class 5 Flexible Plain Copper PVC Insulation PUR (Polyurethane) Sheath PUR-Jz Control Cable image

Get Latest Price Request a quote

Product Details

Model NO.

PUR-JZ

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PUR

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC, VDE

Brand

Huadong

Rated Voltage

300/500V

Amour

Non Armour

Core

2-48 Cores or Customized

Standard

VDE 0295, VDE 0293-334

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Control PUR-JZ Cable

Application

Flexible PUR sheathed cable for tooling machinery,production lines, and flexible applications with free movementand low tensile load. Suitable for dry, ambient and wetenvironments. They are resistant to oil, many chemicals,abrasion, and mechanical stress. These cables can be used inoutdoor applications in fixed installations.

Construction
Conductor Class 5 flexible plain copper wires
Insulation PVC (Polyvinyl Chloride)
Separator Non-woven polyester tape
Sheath PUR (Polyurethane)

Characteristics
Voltage Rating 300/500V
Test Voltage 4kV
Temperature Rating
Fixed: -40°C to +80°C
Flexed: -5°C to +70°C
Minimum Bending Radius
Fixed: 4 x overall diameter
Flexed: 10 x overall diameter

Standard
VDE 0295, VDE 0293-334, VDE 0293-308,VDE 0285-525-1, VDE 0285-525-2-51

Cable Parameter

NO OF CORES	NOMINAL CROSS SECTIONAL AREA mm2	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
2	0.14	3.2	12
2	0.25	3.6	17
2	0.34	4.2	19
2	0.50	5.6	23
2	0.75	5.9	48
2	1	6	61
3	0.14	3.4	17
3	0.25	3.8	21
3	0.34	4.5	19
3	0.51	5.9	31
3	0.75	6	57
4	0.14	3.7	19
4	0.25	4.1	27
4	0.34	4.9	32
4	0.5	6.4	39
4	0.75	6.5	69
4	1	6.5	85
5	0.14	4	22
5	0.25	4.5	32
5	0.34	5.6	38
5	0.5	7	47
7	0.14	4.7	27
7	0.25	5.4	42
7	0.34	6.6	50
7	0.5	7.6	65
8	0.14	5.31	30
8	0.25	6.1	51
8	0.34	7.2	61
8	0.5	7.9	75
12	0.14	5.8	48
12	0.25	6.6	71
12	0.34	7.9	85
12	0.5	9.7	121
