Chj86/Sc Chj86/Nc 250V Tcwb Armored Ship Communication Cable

Chj86/Sc Chj86/Nc 250V Tcwb Armored Ship Communication Cable image

Get Latest Price Request a quote

Product Details

Model NO.

CHJ86/SC

Cover Material

Rubber

Material Shape

Round Wire

Conductor Type

Stranded

Wire Core Material

Tinned Copper

Certification

IEC

Brand

Huadong

Rated Voltage

150/250V

Temperature

-20 Deg to 90 Deg C

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

CHJ86/SC CHJ86/NC 250V TCWB Armored Ship Communication Cable

Cable Structure:Conductor : Stranded tinned copper wire, IEC 60228 Class 2
Insulation : XLPE
Twisted Pair/Triple : Insulated cores twisted together to form a pair/triple
Individual Screen : Plastic coated aluminium tape with a tinned copper drain wire
Covering : Separator Tape
Armor / Shield : Tinned copper wire braid (TCWB)
Sheath : Thermoplastic polyolefine compound (SHF1)
Color: Black or Grey

Application
For fixed installation in most areas and interconnection of Telecommunication & instrumentation on shipboard.

Cable Parameters:

Number of Conductors×Size (mm²)	Nominal Outer Diameter (mm)	Gross Weight (kgs/km)	Number of Conductors×Size (mm²)	Nominal Outer Diameter	Gross Weight (kgs/km)
Number of Conductors×Size (mm²)	Nominal Outer Diameter (mm)	Gross Weight (kgs/km)	Number of Conductors×Size (mm²)	(mm)	Gross Weight (kgs/km)
1×2×0.75	7.2	79	1×2×1.0	7.6	90
2×2×0.75	10	132	2×2×1.0	10.6	153
3×2×0.75	10.5	147	3×2×1.0	11.2	173
4×2×0.75	11.3	178	4×2×1.0	12.1	211
5×2×0.75	12.3	211	5×2×1.0	13.1	252
7×2×0.75	13.3	254	7×2×1.0	14.5	315
10×2×0.75	17	360	10×2×1.0	18.3	438
12×2×0.75	17.3	398	12×2×1.0	18.6	488
14×2×0.75	18.1	443	14×2×1.0	19.7	556
16×2×0.75	19	499	16×2×1.0	20.1	627
19×2×0.75	20.2	562	19×2×1.0	22	710
24×2×0.75	23.2	696	24×2×1.0	25.3	881
27×2×0.75	23.7	754	27×2×1.0	25.8	958
30×2×0.75	24.7	828	30×2×1.0	26.7	1040
33×2×0.75	25.6	903	33×2×1.0	27.9	1149
37×2×0.75	26.5	974	37×2×1.0	28.9	1245
1×2×1.5	8.6	113	1×2×2.5	9.4	145
2×2×1.5	12.3	198	2×2×2.5	13.9	275
3×2×1.5	12.9	222	3×2×2.5	14.7	318
4×2×1.5	14.4	293	4×2×2.5	16	398
5×2×1.5	15.7	353	5×2×2.5	17.6	491
7×2×1.5	17.2	426	7×2×2.5	19.4	606
10×2×1.5	22	604	10×2×2.5	24.8	858
12×2×1.5	22.3	675	12×2×2.5	25.2	973
14×2×1.5	23.5	758	14×2×2.5	26.5	1100
16×2×1.5	24.9	872	16×2×2.5	28.1	1265
19×2×1.5	26.2	973	19×2×2.5	29.6	1426
24×2×1.5	30.4	1223	24×2×2.5	34.4	1795
27×2×1.5	31.1	1334	27×2×2.5	35.5	2028
30×2×1.5	32.2	1452	30×2×2.5	36.8	2213
33×2×1.5	33.6	1605	33×2×2.5	38.4	2442
37×2×1.5	35.1	1783	37×2×2.5	39.9	2663
