Building Wire cUL Certificate Standard Export Drum 14/3 14/2 Nmd90 Cable

Building Wire cUL Certificate Standard Export Drum 14/3 14/2 Nmd90 Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NMD90

Application

Indoor Wire

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC+Nylon

Material Shape

Round Wire

Range of Application

Building Wire

Certification

cUL Certificate

Brand

Ren Da

Production Name

Nmd90 Cable

Certificate

CSA

Voltage

300V

Size

14/2 14/3 12/2 12/3 10/2 10/3 8/2 8/3

Core

2+1, 3+1

Cable Type

Round and Flat

Insulated Material

PVC+Nylon

Sheathed Material

PVC

Market

Canada

Package

75m/Reel or 150m/Reel

Standard

CSA C22.2 No. 48

Name

Non-Metallic Sheathed Cable

Transport Package

Standard Export Drum

Specification

14awg 12awg 10awg 8awg 6awg

Trademark

RNE DA

Origin

Tangshan, Hebei Province

HS Code

8544492100

Production Capacity

300km/Month

Product Description

300V 14/2 12/2 14/3 12/2 NMD90 wire cable with CSA certificate

Application:

NMD90 cables may be used for both exposed work in dry locations or concealed work in dry or

damp locations.The maximum allowable conductor temperature is 90°C. The minimum

recommended installation temperature is -25°C or -40°C for two-conductor cables and -25°C for

three-conductor cables (with suitable handling procedures). Material should be properly stored

above 0°C for 24 hours prior to installation. The maximum voltage rating for all intended

applications is 300 volts. Consult the Canadian Electrical Code1 for further information related to

applications.

Structure:

1. Conductor: Copper conductor with Copper grounding wire 14AWG to 2AWG

or aluminium alloy 8000series

ACM with AL groundig wire Grey 6AWG to 2AWG.

2. Insulation: Polyvinyl chloride (PVC)

3. Protective covering: nylon

4. Jacket: PVC, Heat and moisture-resistant, flame retardant FT1.

5. Number of conductor: 2 parell laid or 3 and 4 round laid

Standard:

CSA C22.2 No. 48 (non-metallic sheathed cable)

UL File No.: E487898

Voltage: 300V

Working temperature:

in dry locations only at temperature not to exceed 90°C

specification.

Size (AWG)	Number of Strands	Ground Wire Size	Insulation Thickness (in)		Allowable Ampacity (Amps)*	Outside Diameter (in)	Approximate Net Weight (lbs/1000 ft)
Size (AWG)	Number of Strands	Ground Wire Size	PVC	Nylon	Allowable Ampacity (Amps)*	Outside Diameter (in)	Approximate Net Weight (lbs/1000 ft)
14/2 G	Solid	14	0.015	0.004	15	0.170 x 0.390	56
12/2 G	Solid	12	0.015	0.004	20	0.160 x 0.450	82
10/2 G	Solid	10	0.020	0.004	30	0.210 x 0.493	123
8/2 G	7	10	0.030	0.005	40	0.290 x 0.580	185
6/2 G	7	10	0.030	0.005	55	0.330 x 0.695	256
14/3 G	Solid	14	0.015	0.004	15	0.170 x 0.450	74
12/3 G	Solid	12	0.015	0.004	20	0.345	107
10/3 G	Solid	10	0.020	0.004	30	0.430	165
8/3 G	7	10	0.030	0.005	40	0.555	251
6/3 G	7	10	0.030	0.005	55	0.612	352
4/3 G	7	8	0.040	0.006	70	0.820	565
2/3 G	7	8	0.040	0.006	95	0.945	841
**14/4 G & 14/2-2 G	Solid	14	0.015	0.004	12	0.345	90
**12/4 G & 12/2-2 G	Solid	12	0.015	0.004	16	0.385	132
**10/4 G	Solid	10	0.020	0.004	30	0.540	205

We are China Building Wire cUL Certificate Standard Export Drum 14/3 14/2 Nmd90 Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
