BS 6724 Copper Conductor Multi Core SWA 1.9/3.3kV 0.6/1kV Power Cable
Application
Multi-core LSZH cable with steel wire armour (SWA). Powerand auxiliary fixed wiring cables for use in power networks,underground,
outdoor and indoor applications and for use incable ducting. For installation where fire, smoke emission andtoxic fumes create a
potential threat to life and equipment.
Characteristics
Voltage Rating Uo/U 0.6/1kV
Temperature RatingFixed intallation: -20°C to +90°C
Minimum Bending Radius
1.5mm2 to 16mm2 – Fixed: 6 x overall diameter
25mm2 and above – Fixed: 8 x overall diameter
Construction
Conductor Class 2 stranded copper conductor
Insulation XLPE (Cross-Linked Polyethylene)
Bedding LSZH (Low Smoke Zero Halogen)
Armour SWA (Steel Wire Armour)
Sheath LSZH (Low Smoke Zero Halogen)
Standards
BS 6724, IEC/EN 60228, IEC/EN 60502-1Low Smoke Zero Halogen according to IEC/EN 61034,
IEC/EN 60754Flame retardant according to EN / IEC 60332-1
|
HIGH ELECTRICAL CONDUCTIVITY COPPER OR ALUMINIUM CONDUCTOR
Copper or aluminium stranded(Class 2) conductors according to lEC 60228
|
|
|
HIGH RESISTANCE PVC/XLPE INSULATION
Available with Cross-linked Polyethylene(XLPE)or Polyvinyl Chloride(PVC) insulation
|
|
|
UV RESISTANCE & FLAME RETARDANT PVC JACKET
Provided with flame retardant PVC jacket to pass flame propagation test to lEC60332-1
|
|
|
CUSTOMIZED DESIGNS
Available in Armoured/Non-armoured and Shielded/Non-shielded constructions
|
|
No. of Cores
|
Conduct Cross Section Area
|
Cable Cross Section Area
|
Actual Armour Cross Section Area
|
Overall Diameter
|
Nominal Weight
|
Resistance of Conductor at 20ºC
|
|
/
|
mm²
|
mm²
|
mm²
|
mm
|
kg/km
|
Ω/Km
|
|
3
|
1.5
|
124.63
|
16
|
12.6
|
330
|
12.1
|
|
3
|
2.5
|
156.07
|
19
|
14.1
|
390
|
7.41
|
|
3
|
4
|
183.76
|
20
|
15.3
|
464
|
4.61
|
|
3
|
6
|
216.31
|
23
|
16.6
|
568
|
3.08
|
|
3
|
10
|
298.5
|
39
|
19.5
|
866
|
1.83
|
|
3
|
16
|
366.25
|
45
|
21.6
|
1152
|
1.15
|
|
3
|
25
|
510.45
|
62
|
25.5
|
1800
|
0.727
|
|
3
|
35
|
615.44
|
68
|
28
|
2230
|
0.524
|
|
3
|
50
|
637.62
|
78
|
28.5
|
2490
|
0.387
|
|
3
|
70
|
813.92
|
90
|
32.2
|
3290
|
0.268
|
|
3
|
95
|
1074.67
|
128
|
37
|
4440
|
0.193
|
|
3
|
120
|
1281.25
|
141
|
40.4
|
5470
|
0.153
|
|
3
|
150
|
1625.15
|
201
|
45.5
|
6930
|
0.124
|
|
3
|
185
|
1946.83
|
220
|
49.8
|
8350
|
0.0991
|
|
3
|
240
|
2383.27
|
250
|
55.1
|
10400
|
0.0754
|
|
3
|
300
|
2844.87
|
269
|
60.2
|
12600
|
0.0601
|
|
3
|
400
|
3481.91
|
304
|
66.6
|
14600
|
0.047
|
