BS 6622 XLPE MDPE 6.35/11 (12) Kv 3X185mm2 Underground Direct Burial Cable

BS 6622 XLPE MDPE 6.35/11 (12) Kv 3X185mm2 Underground Direct Burial Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YJV32

Insulation Material

XLPE

Sheath Material

MDPE

Material Shape

Round Wire

Wire Core Material

Copper Conductor

Certification

ISO, CCC, CE, VDE

Model

Brand

Huadong

Product Name

Medium Voltage Power Cable

Rated Voltage

6.35/11 (12)Kv

Armour

Swa Armoured

Size

3*185mm2

Standards

BS 6622

Cores

3 Core

Type

Direct Burial,Underground

MOQ

100m

Transport Package

by Wooden Drum

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

BS 6622 XLPE/PVC Medium Voltage Power Cable

Application

Power cables for power networks, underground and in cableducting. Suitable for direct burial.

Technical Data

Voltage Rating Uo/U (Um) 6.35/11 (12)kV

Temperature Rating Fixed: 0°C to +90°C

Temperature Index 0°C to +90°C

Minimum Bending Radius 12 x overall diameter

Cable Construction:

Conductor Class 2 stranded copper conductor
Conductor Screen Semi-conductive XLPE (Cross-Linked Polyethylene)
Insulation XLPE (Cross-Linked Polyethylene)
Insulation Screen Semi-conductive XLPE (Cross-Linked Polyethylene)
Separator Water blocking tape
Insulation Screen Semi-conductive XLPE (Cross-Linked Polyethylene)
Metallic Screen Individual copper wire screen
Filler PET (Polyethylene Terephthalate) fibres
Separator Binding tape
Bedding PVC (Polyvinyl Chloride)
Armour SWA (Steel Wire Armoured)
Sheath MDPE (Medium Density Polyethylene)

Voltage	Crossection	Conductor Diameter	Insulation thickness mm	Overall Diameter mm	Weight kg/km
6.35/11kV	35	7	3.4	59.4	5790
6.35/11kV	50	8.2	3.4	62.4	6453
6.35/11kV	70	9.8	3.4	66.4	7495
6.35/11kV	95	11.5	3.4	70.5	8707
6.35/11kV	120	12.9	3.4	74	9763
6.35/11kV	150	14.3	3.4	77.4	10983
6.35/11kV	185	16	3.4	83	12527
6.35/11kV	240	18.4	3.4	88.8	15757
6.35/11kV	300	20.6	3.4	94.1	18204

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane Cables and Other Special Use Cables.

1.what is our payment term ?

Our payment term is usually T/T 30% advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

The lead time usually is 10 – 30 working days.

3.what is the package of the cable ?

The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

Sure, we provide the free sample for customer to checking.

Please feel free to leave your requirement, We will reply you in 12 hours.

We are China BS 6622 XLPE MDPE 6.35/11 (12) Kv 3X185mm2 Underground Direct Burial Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
