Bare Ground Earth Copper Conductor 29mm2

Bare Ground Earth Copper Conductor 29mm2 image

Get Latest Price Request a quote

Product Details

Model NO.

Copper Conductor

Current

AC Cable

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE

Model

29mm2

Brand

Qifan

Standard

IEC BS ASTM

Material

Hard Drawn Copper Wire

Size

29mm2

No of Wires

Conductor Shape

Round

HS Code Number

4107961636

Origin Country

China

Range of Application

Power Station

Transport Package

Export Drum

Specification

120mm2

Trademark

Qifan

Origin

China

Production Capacity

30000km/Month

Product Description

Bare Ground Earth Copper Conductor 29mm2

Description of bare copper conductor

Bare copper, solid or stranded. Available in tempers hard and annealed. The conductors are

concentrically stranded.

Specification of bare copper conductor

BS 7884 : 1997, ASTM B-1; ASTM B-8

Application of bare copper conductor

Solid and stranded bare copper conductors are suitable for overhead transmission and
distribution applications. Stranded conductors of greater flexibility are suitable for
uninsulated hook up, jumpers and grounds in electrical construction.

Installation

Hard drawn copper conductor can be installed in air. It is recommended that the installation instructions

indicated by the Local Electric Code, or any equivalent, be followed, so that the safeguarding of persons and the

integrity of the product will not be affected by deficiencies in the installation.

Specification
ASTM B8

Size	Nominal cross section	Overall diameter	Linear weight	Calculated breaking load	Max.DC resistance of conductor at 20ºC
AWG	mm2	mm	Kg/km	kN	Ohm/km
1	42.4	7.35	377	16.3	0.423
2	33.6	6.54	299	13.3	0.533
4	21.2	5.19	188	8.8	0.848
6	13.3	4.12	118	5.7	1.349
8	8.4	3.26	74	3.7	2.143
10	5.3	2.59	47	2.3	3.409
12	3.3	2.05	29	1.5	5.419
14	2.1	1.63	19	0.9	8.61
16	1.3	1.29	12	0.6	13.715
18	0.8	1.02	7	0.4	21.843

BS 7884

Nominal cross section	No./dia of wire	Overall diameter	Linear weight	Calculated breaking load	Max.DC resistance of conductor at 20ºC
mm2	No./mm	mm	Kg/km	daN	Ohm/km
10	7/1.35	4.05	89.82	3752	1.829
14	7/1.60	4.80	126.2	5267	1.303
16	7/1.7	5.10	142.4	5946	1.154
25	7/2.1	6.3	217.3	9073	0.7563
35	7/2.5	7.5	308	12860	0.5337
50	7/3.0	9.0	435.8	17700	0.3706
70	19/2.1	10.5	593.2	25930	0.2808
95	19/2.50	12.50	840.7	34140	0.198
120	19/2.80	14.0	1055	42830	0.1578
150	19/3.20	18.0	1377	55940	0.1208

We are China Bare Ground Earth Copper Conductor 29mm2 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
