AS/NZS Type 241.1 25mm2 Flexible Rubber Screened Mining Cable

AS/NZS Type 241.1 25mm2 Flexible Rubber Screened Mining Cable image

Get Latest Price Request a quote

Product Details

Model NO.

TYPE 241

Conductor

Flexible Copper

Core

Transport Package

Wooden Drum

Specification

IEC DIN ASTM VDE BS

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

100km/Month

Packaging & Delivery

Package Size

111.00cm * 111.00cm * 111.00cm

Package Gross Weight

111.000kg

Product Description

Flexible Rubber Sheathed Mining Power Cable Type 241.1

Applications:

Type 241 cables are designed for main feeder cable for continuous miners, pump cable and power supply cable. Overall semiconductive screen provides protective earth for any object breaching the sheath prior to contact with power conductors.

Standards:

AS/NZS 1802:2003

AS/NZS 1125:2001

Construction:

• Conductors: Flexible tinned copper conductor, 3 Core, 3 Earths Plus Central Pilot

• Insulation: EPR

• Insulation Screen: Semiconductive Elastomer

• Cradle Separator: Semiconductive Thermosetting

• Overall Core Screen: Semiconductive PCP Filling and Covering

• Textile Reinforcement: Open Weave Braid Reinforcement

• Sheath: Heavy Duty PCP Sheath

Rate Voltage: 1.1/1.1KV

Nominal Conductor Area	Nominal Diameter	Insulation Thickness	Earth Conductor		Pilot Conductor		Overall Sheath Thickness	Nominal Overall Diameter	Nominal Weight
Nominal Conductor Area	Nominal Diameter	Insulation Thickness	Cross Section	Insulation Thickness	Cross Section	Insulation Thickness	Overall Sheath Thickness	Nominal Overall Diameter	Nominal Weight
MM2	MM	MM	MM2	MM	MM2	MM	MM	MM	KG/KM
10	4.2	1.5	1.9	2.6	0.75	1.0	3.8	32.3	1547.3
16	5.4	1.6	3.0	2.8	0.75	1.0	3.9	35.5	1965.3
25	6.9	1.6	4.7	2.6	0.75	1.0	4.2	39.4	2553.6
35	8.4	1.6	6.4	2.5	0.75	1.0	4.4	42.9	3146.9
50	9.8	1.7	8.5	2.6	1.25	1.0	4.9	47.1	3908.3
70	11.55	1.8	13.8	2.5	1.25	1.0	5.3	51.6	4917.2
95	13.22	2.0	13.8	3.0	1.25	1.0	5.8	57.0	6014.1
120	15	2.1	14.8	3.0	1.25	1.0	6.3	62.4	7396.7
150	17.1	2.3	19	3.5	1.25	1.0	6.7	68.7	9046.8
185	18.5	2.5	22.2	3.3	1.25	1.0	7.3	73.8	10691.6
240	21.5	2.8	27.15	3.9	1.25	1.0	8.0	83.0	13544.7
300	23.8	3.0	34.6	4.1	1.25	1.0	8.7	90.2	16245.4

Mining cable is Huatong’s advantage product. We can produce different standard mining cables, including SANS standard and AS/NZS standard. We exported 640/1100V Type 41, Type 61, Type61A, Type61B and Type63, also medium voltage cable Type66, Type611, Type 622 and Type633 to South Africa, Mali, Congo, Tanzania, etc. Besides, there are Type 241.1KV, Type 441, reeling cable and crane cable for Australian and New Zealand markets. High quality, competitive price and fast delivery can meet your requirements.

We are China AS/NZS Type 241.1 25mm2 Flexible Rubber Screened Mining Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
