Arg7h1or Aluminium Rubber Insulated PVC Sheath Medium Voltage Power Cables for Energy Transmission

ARG7H1(O)R Cable

APPLICATION
Medium Voltage power cables suitable for energy transmission between transformer rooms and big power users. For laying on air, into tube or open pass. Suitable for buried installations, and installations complying with art. 4.3.11 of CEI 11-17 standard.
CHARACTERISTICS
Voltage
3.6/6 (7.2)kV,
6/10 (12)kV,
12/20 (24)kV,
18/30 (36)kV
Temperature Rating
-15°C to 90°C
Maximum temperature during short circuit: 250°C
Minimum installation temperature: 0°C
Minimum Bending Radius
12 x Outer diameter
Maximum Tensile Stress 30 N/mm²

CONSTRUCTION
Conductor Class 2, compact stranded aluminium
Conductor Screen Extruded compound (only cables ≥ 6/10 kV)
Insulation HEPR (Hard Grade Ethylene Propylene Rubber) G7 quality, Pb free
Insulation Screen Extruded compound (only cables ≥ 6/10 kV)
Metallic Screen Plain copper tapes wrapped
Filler Extruded, penetrating between the cores
Outer Sheath PVC (Polyvinyl Chloride) compound, Rz quality

STANDARD
CEI 20-13, IEC 60502, CEI 20-16, IEC 60885-3, EN 60332-1-2, EN 60754-1
