Aluminum Service Entrance (SE) Cable with UL854

Aluminum Service Entrance (SE) Cable with UL854

1 Applications:

HUATONG Aluminum Service Entrance Cable Type SE, with rated voltage 600V, is used to transmit power from the junction box to the meter base and from the meter base to the distribution cabinet

It may be used in all applications where Type SE cable is permitted.Type SE cable could be used in dry or wet environmet at the working temperature not exceed 90C.

2 Standard:

ASTM-B-800 and B-801

UL Standard 44 for XHHW-2

UL Standard 854 for SER/SRU

RoHS environmental conductive requirement

3 Product Charactors:

Conductor:AA-8030 aluminum alloy conductors

Insuation:Cross-linked polyethylene(XLPE) Insulation

Jacket: Sunlight resistant,moisture resistant and flame retardant

Temperature Range: Temperature of 90C in wet and dry locations

Environmental: Free of harmful heavy metals in compliance with ROHS

Voltage Rating:600Volt

4 Specification:

The AA-8000 aluminum alloy conductor is applied in Type SER/SEU cable. Its insulated core is complied to the requirment of Type XHHW-2 in UL44. Insulation material is cross-linked polyethylene(XLPE) with characteristics of abrasion resistance,moisture proof and heat resisting.Meanwhile the insulation has the flame retardant property,which can meet FT2 level combustion test requirment. The outside of cable core should be wrapped a fibrage tape,both of the insulation wire core and outer sheathed can meet the 720h sunlight resistance requirment.

5 UL854 certificate of SEU/SER cable:

Certificate

USA is our main market. We have many distributors from USA companies. And we have obtained UL certifications for many products, such as TC cable, DLO cable,RHH/RHW/RHW-2/XHH/XHHW/XHHW-2/SIS, THHN/THHW/THW/THW-2/THWN/THWN-2/TW,SER/SEU/USE/USE-2/MHF, MV-90/MV-105,TC cable,MC cable,DLO,type DG,PV wire,AC Cable,Soow,Welding cable  and so on

Company information:
1 Location:

 Hebei Huatong wires and cables group co., ltd. is Located inTangshan, 100 Km to TianjinXingang sea port, 150Km to the Capital city Beijing China.

2 About Huatong:

Founded in 1993 Registered capital: CNY294 Million Equal to: US$45 Million
Floor space: 220,000 square meter  Employees: 950 Production capacity:US$500Million

3 Production and inspection facility:

Drawing machine : 50 sets
Conductor stranding machine: 30sets
CCV and CV extruding line: 30sets
Insulation and sheath extruding machine: 40sets
Cabling machine: 30sets
Braiding machine:40sets
Other auxiliary machine: 150stes
MV cable partial discharge
equipment: 4sets
Other test machine:100sets

4 Enterprise Principle:

Strengthening Huatong /Benefiting employees /Serving our country and society/Aiming to be a world-renowned enterprise

Our Service:


1.22 years production experience and 13 years export experience .

2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc

3. OEM service available based on official & legal authorization.

4.Strict quality control system.

5.Rapid delivery and feedback  Faster lead time than our competitors.

6.Excellent quality with reasonable price.

7. Strong technical support (technical data, drawing, etc.)

8.Professional teamwork service for you actively.

9.Stock available, Free sample is available.

FAQ:

1.How many year have our factory producing power cable?

Our factory produce power cable for 22 years.

2 Hong Long time the customer can get the new price after get your inquiry?

 Usually , It is only one hour is ok for us , because we are factory , we caculate the price by ourself.

3.Which port our factory is near to?   Tianjin , Qingdao port.

4.Which payment term do we accept?

 T/T 30% in advance and balance before shiping the product or L/C 100% at sight both is ok.

5.What about the package for our power cable?

 It is usually packed in strong wooden drum.The drum size is usually:2.0m x 1.25m x 1.12m x 1.4m which suitable for container , we can do it according to customer requirments.

6.How long meter power cable for one wooden drum?

  This is according to power cable’s diameter and customer’s requirments.

7.How about our delivery time?

  According to your order’s quantity , for 1million meters power cable, it is only 25 working days is ok.

8.Do we provide sample for free?

  Yes , we provide the sample to you for free , you only paid for the delivery freight is ok.
