Aluminum Service Entrance (SE) Cable

Aluminum Service Entrance (SE) Cable image

Get Latest Price Request a quote

Product Details

Model NO.

SER SEU

Application

Heating, Building

Conductor Material

Aluminum or Copper

Sheath Material

Sunlight Resistant Gray Polyvinyl Chloride (PVC)

Insulation Material

XLPE/PVC

Material Shape

Flat Wire or Round Wire

Range of Application

Conduit or Recognized Raceways for Services

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Voltage

600V

Transport Package

Coils and Drums

Specification

8AWG TO 2000MCM

Trademark

Renda

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

APPLICATION
Type SE, service entrance cable is primarily used to convey power from the service drop to the meter base and from the meter base to the distribution panelboard; however, the cable may be used in all applications where Type SE cable is permitted. SER may be used in wet or dry locations at temperatures not to exceed 90°C. Voltage rating is 600 volts.

PRODUCT FEATURES

Type SE cable is constructed with AA-8000 series aluminum alloy, compact stranded conductors.
Cross-linked polyethylene insulation rated for a maximum operation temperature of 90°C in wet and dry locations.
Eco friendly sunlight resistant, flame retardant and heavy metal free Polyvinyl Chloride (PVC) Jacket.
Insulation and Jacket materials are in compliance with RoHS, Directive 2002/95/EC.
Sequential foot markings for easier inventory control management.

STANDARDS & REFERENCES

Type SE cable complies with :

• ASTM- All applicable standards

• UL Standard 44 for XHHW-2 conductors

• UL Standard 83 for THHN/THWN conductors

• UL Standard 854

• Federal Specification A-A-59544

• National Electrical Code, NFPA 70. 2011 Edition

• RoHS/ REACH

CONSTRUCTION

Conductor: compact copper or AA-8000 series aluminum alloy, compact stranded

Insulation:Cross-linked polyethylene(XLPE) insulation with property of heat.Moistrure and abrasion resistance and flame retardant.

Sheath:sunlight resistant gray polyvinyl chloride (PVC).

Type SE cable is constructed with sunlight resistant Type XHHW-2 conductors or Type THHN/THWN conductors.Cable assembly plus reinforcement tape are jacketed with sunlight resistant gray polyvinyl chloride (PVC). Available as 1 conductor with a concentric ground, 2 conductor with a round or concentric

ground, or 3 conductor with a bare ground. SE cable is jacketed with gray sunlight resistant polyvinyl chloride (PVC).

Aluminum Specifications:

Service Entrance Cable Style R (SER) – 2 Conductor with Ground SER
Size AWG & Construction	Stranding		Nominal	Weight per	Ampacity (AMPS) *
	Stranding		Diameter	1000 ft.	Ampacity (AMPS) *
	Phase	Equipment Ground	(in)	(lbs)	90˚ C	Dwelling
	Conductors	Conductor			90˚ C	Dwelling
6-6-6	7	–	0.65	150	60	–
4-4-6	7	–	0.681	196	75	–
4/4/4	7	–	0.682	196	75	–

Service Entrance Cable Style R (SER) – 3 Conductor with Ground SER
Size AWG & Construction	Stranding		Nominal	Weight per	Ampacity (AMPS) *
	Stranding		Diameter	1000 ft.	Ampacity (AMPS) *
	Phase	Equipment Ground	(in)	(lbs)	90˚ C	Dwelling
	Conductors	Conductor			90˚ C	Dwelling
8-8-8-8	Solid	Solid	0.588	128	45	–
6-6-6-6	7	7	0.684	180	60	–
4-4-4-6	7	7	0.754	240	75	–
2-2-2-4	7	7	0.893	344	100	100
1-1-1-3	19	7	1.003	432	115	110
1/0-1/0-1/0-2	19	7	1.097	521	135	125
2/0-2/0-2/0-1	19	19	1.197	633	150	150
3/0-3/0-3/0-1/0	19	19	1.314	771	175	175
4/0-4/0-4/0-2/0	19	19	1.443	942	205	200
250-250-250-3/0	37	19	1.601	1106	230	225

Service Entrance Cable Style R (SER) – 4 Conductor with Ground SER
Size AWG & Construction	Stranding		Nominal	Weight per	Ampacity (AMPS) *
	Stranding		Diameter	1000 ft.	Ampacity (AMPS) *
	Phase	Equipment Ground	(in)	(lbs)	90˚ C	Dwelling
	Conductors	Conductor			90˚ C	Dwelling
2-2-2-2-4	7	7	1.004	450	100	100
2/0-2/0-2/0-2/0-1	19	19	1.346	824	150	150
4/0-4/0-4/0-4/0-2/0	19	19	1.621	1226	205	200
250-250-250-250-3/0	37	19	1.95	1454	230	225

1. Data are approximate and subject to normal manufacturing tolerances.
2. Standard lengths are subject to normal manufacturing tolerance of +/- 10%
3. To determine correct ampacity by conductor size, please consult the National Electric Code, latest edition.
4. Table values reflect XHHW-2 aluminum conductors
5.Package:A-500′ B-2,500′ C-1,000′ D-5,000′

UL Certificate for XHHW,SER,SEU,MC Cable
