Aluminum Copper PV Cables Solar Photovoltaic Cable Single Conductor Rpv90

Aluminum Copper PV Cables Solar Photovoltaic Cable Single Conductor Rpv90 image

Get Latest Price Request a quote

Product Details

Model NO.

RPV90

Sheath Material

Crosslinking

Insulating Material

XLPE

Conductor Type

Stranded

Brand

Huatong Cables

Certification

cUL

Wire Core Material

Bare Copper Wire

Transport Package

Spools

Specification

14AWG 12AWG 10AWG 2AWG 500MCM 750MCM 2/0AWG 4/0AWG

Trademark

Huatong Cables

Origin

China

HS Code

8544492100

Production Capacity

12 Containers Per Month

Product Description

600V Type RPV90 Photovoltaic Cable

Conductor: annealed bare copper wires, or compact aluminum 8000 series wires (ACM), class B.
Insulation: Heat and moisture resistant, low temperature Cross-Linked Polyethylene (XLPE)

Colour Coding: Black or red; other colours available upon request.

Application: For use in interconnection wiring of grounded and ungrounded photovoltaic power systems, in dry and wet locations. For exposed wiring where subjected to the weather, marked sunlight resistant “SR”; For use in raceways, except cable trays, in wet, damp, or dry locations.

Standard: CSA C22.2 No. 38 Thermoset-Insulated Wires and Cables; CSA C22.2 No. 271 Photovoltaic cables

Working temperature: -40ºC to +90ºC

Voltage: 600V

Conductor			Insulation thickness	Approx. OD (mm)
AWG/kcmil	Nos of strands(CU)	Nos of strands(ACM)	(mm)	CU	AL
1X14	1 or 7	/	0.76	3.2	3.2
1X12	1 or 7	7	0.76	3.7	3.7
1X10	1 or 7	7	0.76	4.2	4.2
1X8	7	7	1.14	6.0	5.8
1X6	7	7	1.14	7.0	6.7
1X4	7	7	1.14	8.2	7.8
1X2	7	7	1.14	9.7	9.2
1X1/0	19	18	1.40	12.2	11.4
1X2/0	19	18	1.40	13.3	12.4
1X3/0	19	19	1.40	14.6	13.6
1X4/0	19	19	1.40	16.0	15.0
1X250	37	36	1.65	17.7	16.7
1X350	37	36	1.65	20.3	19.1
1X400	37	36	1.65	21.2	20.2
1X500	37	36	1.65	23.0	22.1
1X750	61	58	2.03	28.7	27.3

Package: By coils or spools according to clients’ requirement.

Largest manufacturer of UL cUL approved cables in China!

Pls contact us for details!
