Aluminum 10/16/25/35mm2 Outdoor Twisted Cable ABC Overhead Bundled Cable Wire

Aluminum 10/16/25/35mm2 Outdoor Twisted Cable ABC Overhead Bundled Cable Wire image

Get Latest Price Request a quote

Product Details

Model NO.

BLV

Application

Overhead, Heating, Underground, Urban Development, Rural Electrification

Conductor Material

Aluminum

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Tree-Rich Areas, Industrial Applications.

Certification

ISO9001, CE, CCC, RoHS

Brand

Qif

Insulation Color

Customized

Min Quantity

1000m

Conductor Grade

1350-H19, 6208-T81

Service

OEM ODM

Packing Size

100m/Roll, 305m/Roll, Wrap Plastic Film Packaging

Transport Package

Coil/Spool/Carton/Pallet/Wooden Drum

Specification

multi-core

Trademark

QIF

Origin

China

HS Code

85444929

Production Capacity

500000m/Month

Product Description

Two-core Parallel Anti-aging Wire

Specification
2*2.5, 2*4, 2*6, 2*10, 2*16, 2*25, 2*35 square

Advantages
1. Wind resistance. The wire conductor is elastic, which greatly enhances the outdoor wind resistance and can withstand 6-7 level gale.
2. Rain and sun resistance. The outer layer of polyvinyl chloride insulation has a tight structure, smooth surface, high strength, and can prevent sunlight and rain erosion for a long time.

3.Suitable for indoor pipe wearing and outdoor working temperature, especially in cold areas. The long-term allowable working temperature of the wire should not exceed +65ºC.

Parameters

Item	DESCRIPTION	UNIT	TENDERED
1	TYPE		AAC/PVC Covered 2c16mm2
1	Rated voltage	kV	0.6/1
2	Applies Standard		BS 6485; IEC 61059
3	Conductor
	Material	–	Hard drawn aluminium
	Normal section area	mm²	16
	Conductor shape	–	Stranded Circular
	Number of core	each	2
	Number and diameter of individual wire	No./mm	7/1.70
	Conductor diameter	mm	5.1
4	Insulation
	Material	–	PVC(weather resistant)
	Color	–	Black
	Average insulation Thickness	mm	≥1.0
	Minimum insulation thickness at any point	mm	0.8
5	Core identification		Number and Ribs
6	Approx.Overall/Outer diameter of cable	mm	4.0 15.5
7	Max. DC.conductor resistance at 20ºC	Ohm/km	1.813
8	Per core Breaking strength	KN	2.827
9	Approx. weight of cable	Kg/km	150
10	Packing
	Length of cable per drum/reel	m	6000
	Material of drum (non-returnable)	–	Wooden
11	Cable Marking		as customer required

How can I get some samples?

We provide free sample and will courier to you by DHL, FEDEX, UPS, TNT, etc. swiftly according to your requirements.

How do you control the quality?
QC department will control the quality during the full production process.
Inspector will inspect each item according to the order, inspection report will transfer to you before loading.
Any third party inspection will be accepted during the production or before loading, such as SGS, BV, etc.
After-sale dept will follow the order and pay high attention on the feedback from your side after all the products delivered. Any quality problem, we will arrange the technical personnel to solve and bear the corresponding customer losses..

What if the cable we need have some differences on specifications from yours?
Any differences, we can design and produce according to your requests.

What’s the package of the goods?
Usually wooden or steel drum or coil, or according to your requirement

What’s the lead time?
Usually 10-30 working days.

Welcome your inquiry and email soon……

We are China Aluminum 10/16/25/35mm2 Outdoor Twisted Cable ABC Overhead Bundled Cable Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
