Aluminium Conductor XLPE Insulated Power Cable RV, Rz1, Aluminium Cable

Aluminium Conductor XLPE Insulated Power Cable RV, Rz1, Aluminium Cable image

Get Latest Price Request a quote

Product Details

Model NO.

RV AL, RZ1 AL

Application

Underground

Conductor Material

Copper or Aluminium

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Power Transmission

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

QIFAN

Shielded

Armoured

Color of Sheath

Black or Customized

Leadtime

15days

Transport Package

Iron Drums

Specification

as per requirements

Trademark

Qifan

Origin

China

HS Code

8544492100

Product Description

1. Conductor
- Aluminium, class 2 based on EN 60228 and IEC 60228.
2. Insulation
- Cross-linked polyethylene type DIX-3 according to HD 603 (XLPE) according to IEC 60502-1 and compound insulation according to XP C 32-321.
- The standard identification of insulated conductors according to HD 308, is the following:
- 1x Natural2x Blue + Brown
- 3x Brown + Black + Grey
- 3x + 1 Brown + Black + Grey + Blue (reduced cross-section)
- 4G Brown + Black + Grey + Green/Yellow
- 4x Brown + Black + Grey + Blue
3. Outer sheath
- Flexible PVC, type DMV-18 according to HD 603, type ST2 according to IEC 60502-1 and compound outer sheath according to XP C 32-321. Black or grey color.

R	XLPE (Cross-linked Polyethylene) Insulation
H	Semi conducting screen and metallic screen added.
Z1	Polyolefin compound
OL	Longitudinal watertightness over the insulation screen only
2OL	Longitudinal watertightness in conductor and over insulation screen
(S)	Type 10E-4 (following HD620 Type 10E -4)
(AS)	Type 10E-5 (following HD620 Type 10E -5)
K	Compacted round shape conductor
+H	Nominal Metallic screen cross sectional are in mm²
AL	Aluminium Conductor

It is manufactured under IEC60502-1 standard.Flame-retardant PVC insulated power cable is manufacturedunder the enterprise standard with reference to IEC60502-1 on flame-retardant performance.Lowsmoke & Low-halogen flame-retardant PVC insulated powercable is manufactured as the enterprise standard with reference to IEC standard on flame-retardantperformance.
Lowsmokehalogen-freeflame-retardant PVC insulated powercable is manufactured as the enterprise standard with reference to International Standards flame-retardantperformance.

Max. Resistance of Class 2 Conductor at 20ºC

Nominal Cross-sectional Area of Conductor (Sq.mm)	Max. Resistance of Class 2 Conductor at 20ºC (Ω/km)
Nominal Cross-sectional Area of Conductor (Sq.mm)	Copper Conductor	Aluminum Conductor
0.5	36.0
0.75	24.5
1	18.1
1.5	12.1
2.5	7.41
4	4.61	7.41
6	3.08	4.61
10	1.83	3.08
16	1.15	1.91
25	0.727	1.20
35	0.524	0.868
50	0.387	0.641
70	0.268	0.443
95	0.193	0.320
120	0.153	0.253
150	0.124	0.206
185	0.0991	0.164
240	0.0754	0.125
300	0.0601	0.100
400	0.0470	0.0778
500	0.0366	0.0605
630	0.0283	0.0469
800	0.0221	0.0367

We are China Aluminium Conductor XLPE Insulated Power Cable RV, Rz1, Aluminium Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
