Alimentador Ttu Flex Cable 3*250mcm+250mcm+1/0AWG Cu-Ttu 600V Cables for Venezuela Market

Alimentador Ttu Flex Cable 3*250mcm+250mcm+1/0AWG Cu-Ttu 600V Cables for Venezuela Market image

Get Latest Price Request a quote

Product Details

Model NO.

TTU CABLE

Current

DC & AC

Insulation Material

XLPE

Sheath Material

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, RoHS

Model

Ttu

Brand

Ht Cables

Installation

Underground

Certifications

ISO

Applicated

Industrial

Temperature

70c

Color

Black

Transport Package

Standard Export Drums

Specification

250MCM

Trademark

HT cables

Origin

China

HS Code

854460

Production Capacity

1000000meter Per Month

Product Description

TYPE TTU 10AWG 8AWG 6AWG Thermoplastic undeground cable electrical wire wholesale

Description

Soft copper conductor, XLPE or PE insulated and an PVC external jacket.

Uses and Applications

For use in building and industrial instalations, especially in subterraneas line mainly for underground service.

CONSTRUCTION ELEMENTS

Conductor
Compressed Stranded Soft copper.

Insulation

Thermoplastic Polyethylene (PE 75°•’3fC), for PE-PVC. Cross Linked Polyethylene (XLPE 90°•’3fC), for XLPE-PVC.

Options

Aluminum Conductor, PVC-LS (Low smoke emissions) jacket and PVC SR (Sunlight resistant) jacket
For sizes greater than 1/0 AWG, Type Tray Cable (TC).

Characteristics
Operating temperature Dry and wet locations. 75°C for TTU PE -PVC.
90°C for TTU XLPE -PVC.
Operating Voltage600 V

Standards and Specifications

CENTELSA TTU Cables are manufactured under the following standards:
ASTM B3, NTC-ICONTEC 359. Soft copper wire.
ASTM B8, NTC-ICONTEC 307. Concentric Lay Stranded copper conductors.
ASTM B787. 19 Wire Combination Unilay Stranded Copper conductors for subsequent insulation.
UL 1581, NTC-3203. Reference Standard for Electrical Wires, Cables and Flexible Cords. ICEA S-95-658, NTC-ICONTEC 1099-1. Power Cables rated 2000 volts or less for the Distribution of Electrical Energy.

SIZE	STRANDS	STRANDING	CROSS	CONDUCTOR	INSULATION	DIAMETER	JACKET	DIAMETER	APPROX.	DC RESISTANC
AWG /	No.	CLASS	SECTION	DIAMETER	THICKNESS	OVER INSULATION	THICKNESS	OVER JACKET	TOTAL WEIGHT	AT 20°C
kcmil			(mm2)	(mm)	(mm)	(mm)	(mm)	(mm)	(kg/km)	(ohm/km)
14	7	B	2.08	1.79	0.76	3.38	0.38	4.06	33	8.45
12	7	B	3.31	2.25	0.76	3.85	0.38	4.56	46	5.31
10	7	B	5.26	2.85	0.76	4.44	0.38	5.16	66	3.34
8	7	B	8.37	3.59	1.14	5.96	0.38	6.66	104	2.1
6	7	B	13.3	4.52	1.14	6.89	0.76	8.32	166	1.32
4	7	B	21.15	5.71	1.14	8.08	0.76	9.52	244	0.831
2	7	B	33.63	7.2	1.14	9.57	0.76	11.02	363	0.523
1	19	B	42.41	8.18	1.4	11.09	1.14	13.28	482	0.415
1/0	19	B	53.48	9.18	1.4	12.09	1.14	14.28	589	0.329
2/0	19	B	67.43	10.31	1.4	13.22	1.14	15.38	721	0.261
3/0	19	B	85.03	11.58	1.4	14.49	1.14	16.68	888	0.207
4/0	19	B	107.2	13	1.4	15.91	1.14	18.08	1093	0.164
250	37	B	126.7	14.18	1.65	17.61	1.14	19.78	1296	0.139
300	37	B	152	15.52	1.65	18.95	1.65	22.40	1632	0.116
350	37	B	177.3	16.78	1.65	20.21	1.65	23.40	1848	0.0992
400	37	B	202.7	17.94	1.65	21.37	1.65	24.80	2125	0.0868
500	37	B	253.4	20.04	1.65	23.47	1.65	26.60	2567	0.0694
600	61	B	304.	22	2.03	26.18	1.65	29.61	3130	0.0578
700	61	B	354.7	23.75	2.03	27.93	1.65	31.36	3616	0.0496
750	61	B	380	24.59	2.03	28.77	1.65	32.00	3858	0.0463
800	61	B	405.4	25.39	2.03	29.57	1.65	33.00	4100	0.0434
900	61	B	456	26.94	2.03	31.12	1.65	34.56	4583	0.0386
1000	61	B	506.7	28.38	2.03	32.56	1.65	35.80	5064	0.0347

We are China Alimentador Ttu Flex Cable 3*250mcm+250mcm+1/0AWG Cu-Ttu 600V Cables for Venezuela Market manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
