Ahxamk-W 3X300+35 12/20 (24) Kv 3-Core Medium Voltage Power Cable

Ahxamk-W 3X300+35 12/20 (24) Kv 3-Core Medium Voltage Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

AHXAMK-W

Current

DC & AC

Insulation Material

XLPE

Sheath Material

Material Shape

Round Wire

Wire Core Material

Stranded Aluminium

Certification

HD 620 10 F, Sfs 5636

Brand

Huadong

Rated Voltage

12/20 (24) Kv

Cores

Three Core

Type

Water Resistant

Size

35-630mm2

Standard

HD 620 S2 10f

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Ahxamk-W 3X300+35 12/20 (24) Kv 3-Core Medium Voltage Power Cable

Medium-voltage cable for fixed installations outdoors. May be buried directly in soil, also by ploughing. Cable is longitudinally and radially

watertight and therefore it is suitable where wet soil and / or fresh water permanently occurs. Installations must be in accordance with national

regulations and rules of installations. The cable is halogen-free, but without fire protection. The cable is not CPR-classified.

CONSTRUCTION

Conductor Class 2 watertight, circular, stranded aluminium

Conductor Screen Semi conducting XLPE (Cross-Linked Polyethylene)

Insulation XLPE (Cross-Linked Polyethylene)

Insulation Screen Semi conducting XLPE (Cross-Linked Polyethylene)

Metallic Screen Aluminium/plastic laminate (Acts as a radial water barrier)

Outer Sheath PE (Polyethylene)

Cable Lay Up Three sheathed cores laid up around a bare earth conductor

STANDARDS

HD 620 10-F, SFS 5636, EN/IEC 60228

CHARACTERISTICS

Voltage Uo/U(Um)

12/20 (24)kV

19/33 (36)kV

Temperature Rating

-50°C to +90°C

Max. conductor temperature during short circuit max. 5s: +250°C

Minimum temperature during handling: -20°C

Minimum temperature during transport: -40°C

NO.OF CORES	NOMINAL CROSS SECTIONAL AREA mm2	NOMINAL EARTH CONDUCTOR AREA SIZE mm2	NOMINAL EARTH CONDUCTOR DIAMETER mm	NOMINAL DIAMETER OVER INSULATION WITHOUT SCREEN mm	NOMIN AL INSULATION THICKNESS mm	NOMINAL THICKNESS OF ALUMINIUM LAMINATED FOIL mm	NOMINAL OUTER SHEATH THICKNESS mm	NOMINAL OUTER DIAMETER OF COMPLETE CABLE mm	NOMINAL WEIGHT kg/km
3	50	35	6.9	19.3	5.5	0.2	2.8	59	2243
3	70	35	6.9	20.7	5.5	0.2	2.8	62	2531
3	95	25	–	22.4	5.51	0.2	2.9	66	2817
3	95	35	6.9	22.4	5.5	0.2	2.9	66	2905
3	120	35	6.9	23.4	5.5	0.2	2.9	68	3200
3	150	35	6.9	25.1	5.5	0.2	2.9	71	3570
3	185	35	6.9	27.0	5.5	0.2	3.0	76	4091
3	185	50	8.2	27.0	5.5	0.2	3.0	76	4191
3	185	70	9.9	27.0	5.5	0.2	3.0	76	4373
3	240	35	6.9	29.2	5.5	0.3	3.1	82	4868
3	240	70	9.9	29.2	5.5	0.3	3.11	82	5173
3	300	35	6.9	31.0	5.5	0.3	3.2	86	5603
3	300	70	9.9	31.0	5.5	0.3	3.2	86	5893

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,China.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China Ahxamk-W 3X300+35 12/20 (24) Kv 3-Core Medium Voltage Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
