Acwu90 Wire 600V CSA 250mcm Aluminum XLPE FT4 Power Cable

Acwu90 Wire 600V CSA 250mcm Aluminum XLPE FT4 Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

ACWU90

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Aluminum

Certification

CSA

Model

Acwu90

Brand

Ht Cables

Product Name

Acwu90 Cable

Core

2+1, 3+1, 4+1

Standard

CSA C22.2 N° 51

cUL File No

E466697

Flame Retardant

FT4

Transport Package

305m/Spool

Specification

2/0 3/0 4/0 250 350 500 750

Trademark

HT cables

Origin

Tangshan, Hebei Province

HS Code

8544492100

Production Capacity

500km/Month

Packaging & Delivery

Package Size

1.20cm * 1.20cm * 1.30cm

Package Gross Weight

10000.000kg

Product Description

CSA certificate 600V 4C 250MCM 500MCM ACWU90 Cable Factory Price

Application:

For open and concealed wiring in dry locations only.For use in cabletroughs and ventilated flexible cable ways in dry locations only. Minimum recommended installation temperature minus 40°C (with suitable handling procedures).Maximum conductor temperature 90°C. Approved for use with ceiling fixtures.Armoured cable for commercial, industrial and apartment use

Structure:

Conductor: Copper conductor with Copper grounding wire 14AWG to 2AWG or aluminium alloy 8000series ACM with AL grounding wire 6AWG to 750MCM
Insulation: cross-linked polyethylene insulation (RW90 XLPE
Assemble wrap: Conductor assembly paper wrapped
Armored : bare interlocked aluminum armor.
5. Sheath: PVC Sheath
6. Number of conductor: Two, three or four core round laid

Standard: National : CSA C22.2 N° 2556; CSA C22.2 N° 51

UL File No.: E466697

Voltage:600V

Working temperature:

in dry locations only at temperature not to exceed 90°C.

Performance:

FT4 Flame retardant; Lead free and ROHS compliant. Limited Smoke Zero Halogen

Printing:

HT CABLES c(UL) E466697 250AWG 3C ACWU90 Armored CABLE FT4 600V (-40ºC) xxx m 2023

AL Conductor with bare AL aluminum tape interlocked armoured size series in 3 and 4 core

No of phase	Size	Insulation thickness	Bonding wire Size	PVC Jacket	Approximate Total Diameter	Approximate Net Cable Weight
No of phase	Awg or kcmil	MM	Awg	mm	MM	kg/km
3	6	1.14	8	1.27	21.6	807.41
3	4	1.14	6	1.27	24.2	980.79
3	3	1.14	6	1.27	25.4	1071.4
3	2	1.14	6	1.27	27	1188.4
3	1	1.4	4	1.27	29.9	1411.6
3	1/0	1.4	4	1.27	31.8	1575.2
3	2/0	1.4	4	1.27	34	1772.8
3	3/0	1.4	4	1.27	36.6	2015.2
3	4/0	1.4	4	1.27	39.5	2304.1
3	250	1.65	2	1.52	43.5	2668.4
3	300	1.65	2	1.52	46.2	2980.2
3	350	1.65	2	1.52	48.8	3281
3	400	1.65	2	1.52	51.1	3584.2
3	500	1.65	1	1.52	58.7	4712.7
3	600	2.03	1	1.9	65.4	5478.4
3	750	2.03	1	1.9	67.2	6245.3
4	6	1.14	8	1.27	23.7	931.88
4	4	1.14	6	1.27	26.6	1141.9
4	3	1.14	6	1.27	28	1256.4
4	2	1.14	6	1.27	29.8	1401.9
4	1	1.4	4	1.27	33.2	1674.9
4	1/0	1.4	4	1.27	35.3	1881.3
4	2/0	1.4	4	1.27	37.7	2126.3
4	3/0	1.4	4	1.27	40.1	2416.1
4	4/0	1.4	4	1.27	43.8	2781.4
4	250	1.65	2	1.52	51.2	3708.4
4	300	1.65	2	1.52	54.3	4128.9
4	350	1.65	2	1.52	57.1	4534.4
4	400	1.65	2	1.52	59.7	4942.6
4	500	1.65	1	1.9	65.2	5733.4
4	600	2.03	1	1.9	71.8	6704
4	750	2.03	1	1.9	77.6	7847.1

We are China Acwu90 Wire 600V CSA 250mcm Aluminum XLPE FT4 Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
