ACSR Neutral 2/0AWG XLPE Insulation Aerial Twisted Cable with ASTM Standard
ACSR Neutral 2/0AWG XLPE Insulation Aerial Twisted Cable with ASTM Standard image
Get Latest Price Request a quote
You May Like
Product Details
Current
AC Cable
Insulation Material
XLPE
Material Shape
Round Wire
Wire Core Material
Aluminum
Certification
ISO, CCC, CE
Model
ABC
Brand
Qifan
Standard
Icea S-76 474
Color
Black
Conductor
1350 Aluminum
Neutral Core
AAC AAAC ACSR
Core No
Two
Conductor Working Temperature
90 Degrees
Rated Voltage
600 V
Using
Delivery Electrical Power
Transport Package
Wooden Export Drum
Specification
6AWG
Trademark
Qifan
Origin
China
Production Capacity
20000km/Month
Product Description
ACSR Neutral 2/0AWG XLPE Insulation Aerial Twisted Cable with ASTM Standard
Application
Duplex Overhead Aluminum Cable
This duplexed cable is suited for use as drop cable from a pole mounted transformer to the service entrance of a structure, or as secondary distribution between poles. The cable should be limited to 600V phase to phase and not exceed 90˚C.
This duplexed cable is suited for use as drop cable from a pole mounted transformer to the service entrance of a structure, or as secondary distribution between poles. The cable should be limited to 600V phase to phase and not exceed 90˚C.
Aluminum Duplex Overhead Service Drop Cable Features
• Conductor
Compressed 1350-H19 series are lightweight and flexible hence easy to install and move around.
• Insulation
The thermoplastic XLPE is non-conducting hence keeping the user safe from electric shocks. It ensures that the live conductors do not get into contacts with the messenger wire, as well as offering chemical and mechanical protection.
• Messenger Wire
They are designed with an operational temperature of up to 90 degrees and a voltage rating at 600 volts.
Aluminum Duplex Overhead Service Drop Cable Specifications:
| PRODUCT | PHASE CONDUCTOR SIZE | PHASE CONDUCTOR STRANDING | BARE NEUTRAL MESSENGER SIZE | BARE NEUTRAL MESSENGER STRANDING | NEUTRAL TYPE |
| Collie | 6 | 7 | 6 | 7 | AAC |
| Dachshund | 4 | 1 | 4 | 7 | AAC |
| Spaniel | 4 | 7 | 4 | 7 | AAC |
| Doberman | 2 | 7 | 2 | 7 | AAC |
| Malemute | 1/0 | 19 | 1/0 | 7 | AAC |
| Setter | 6 | 1 | 6 | 6/1 | ACSR |
| Shepherd | 6 | 7 | 6 | 6/1 | ACSR |
| Eskimo | 4 | 1 | 4 | 6/1 | ACSR |
| Terrier | 4 | 7 | 4 | 6/1 | ACSR |
| Chow | 2 | 7 | 2 | 6/1 | ACSR |
| Bull | 1/0 | 19 | 1/0 | 6/1 | ACSR |
| Chihuahua | 6 | 1 | 6 | 7 | 6201 Alloy |
| Vizsla | 6 | 7 | 6 | 7 | 6201 Alloy |
| Harrier | 4 | 1 | 4 | 7 | 6201 Alloy |
| Whippet | 4 | 7 | 4 | 7 | 6201 Alloy |
| Schnauzer | 2 | 7 | 2 | 7 | 6201 Alloy |
| Heeler | 1/0 | 19 | 1/0 | 7 | 6201 Alloy |
More Aluminum Duplex Overhead Service Drop Cable detail all in :
- Service Drop Wire Philippines
- 6-6 shepherd aluminum duplex overhead service drop cable
- 4-4 terrier aluminum duplex overhead service drop cable
- 2-2 chow aluminum duplex overhead service drop cable
Aluminum Duplex Overhead Service Drop Cable Standards:
ASTM B-230
ASTM B-231
ASTM B-232
ASTM B-399
ICEA S – 76 – 474
We are China ACSR Neutral 2/0AWG XLPE Insulation Aerial Twisted Cable with ASTM Standard manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
