9yslcy 9yslcy-Jb 9yslcyk-Jb+3 EMC-Optimised Motor Power Supply Servo Drive System Cable

9yslcy 9yslcy-Jb 9yslcyk-Jb+3 EMC-Optimised Motor Power Supply Servo Drive System Cable image

Get Latest Price Request a quote

Product Details

Model NO.

9YSLCY

Current

DC & AC

Insulation Material

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper

Certification

VDE

Brand

Huadong

Rated Voltage

0.6/1kv

Size

1.5-240mm

Cores

4 Cores and 3+3 Cores

Standard

DIN VDE 0250

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

9YSLCY 9YSLCY-JB 9YSLCYK-JB+3 EMC-optimised Motor Power Supply Servo Drive System Cable

Application
Connecting cable between frequency converter and motor In dry, damp or wet interiors
Paper industry
Chemical industry
Heavy industry

Construction
Fine-wire, bare copper conductor
Core insulation: polypropylene (PP)
Cores twisted concentrically (symmetrically splitted protective conductor of 3+3 version is gusset-filling divided between the power cores)
Screening: wrapping of laminated aluminium foil in combination with tinned copper braiding
4-core design: transparent PVC outer sheath
3+3 core version: PVC outer sheath, black

Product Benefits
EMC-compliant operation of power drive systems
High power transmission for large drives
Low capacitance design enables longer cable connection between frequency converter and motor
Symmetrical 3+3 Version supports the reduction of damaging bearing currents
Versions with black outer sheath are suitable for outdoor use

Cable Parameters

Number of cores and mm per conductor	Outer diameter [mm]	Copper index (kg/km)	Weight (kg/km)
9YSLCY-JB / 4-core version – transparent outer sheath
4 G 1,5	10.5	87	230
4 G 2,5	11.8	133	300
4 G 4	13.3	213	485
4 G 6	14.9	298	630
4 G 10	17.7	460	860
4 G 16	21.5	707	1290
4 G 25	26.3	1100	1860
4 G 35	29.7	1542	2610
4 G 50	35.8	2206	2950
4 G 70	40.9	3002	3950
4 G 95	45.4	4004	5300
4 G 120	49.8	5108	6600
4 G 150	56.1	6225	7590
4 G 185	61.4	7568	9420
4 G 240	67.9	9940	12150
9YSLCY-JB / 3+3 core version – black outer sheath
3 X 1,5 + 3 G 0,25	11.4	88	177
3 X 2,5 + 3 G 0,5	12.9	130	220
3 X 4 + 3 G 0,75	13.6	224	323
3 X 6 + 3 G 1,0	15.2	276	420
3 X 10 + 3 G 1,5	17.4	511	635
3 X 16 + 3 G 2,5	20	751	930
3 X 25 + 3 G 4	24.3	1204	1350
3 X 35 + 3 G 6	27.5	1535	1780
3 X 50 + 3 G 10	31.1	2156	2530
3 X 70 + 3 G 10	37.1	2980	3225
3 X 95 + 3 G 16	40	3953	4511
3 X 120 + 3 G 16	42.6	4836	5663
3 X 150 + 3 G 25	50	5412	6720
3 X 185 + 3 G 35	55.6	7077	7855

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China 9yslcy 9yslcy-Jb 9yslcyk-Jb+3 EMC-Optimised Motor Power Supply Servo Drive System Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
