8.7/15kv 18/30kv N2xsy/Na2xsy Cu or Al/XLPE/Cws/Cts/PVC Red Color Power Cable

TOP TEN CABLE MANUFACTURER IN CHINA

LARGEST CABLE MANUFACTUER IN NORTH CHINA

ANNUAL EXPORT VOLUME EXCEED 200MILLION USD

WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD’S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS

WITH TUV TYPE TESTING REPORT

WIDE PRODUCTS RANGE

ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS

CNAS APPROVAL LABROTARY

Product Description

1. Standard of XLPE Cable: According to GB12706( Equal to IEC60502)Also can do by standard of ASTM,BS,DIN and AS/NZS or other standards as request.

2. Rated Voltage of XLPE Cable:

0.6/1KV 6/10KV;8.7/15KV;12/20KV;18/20KV;21/35KV;6/35KV

3. Construction of XLPE Cable:

Conductor:Copper or Aluminum

Insulation:XLPE

Inner sheath:PVC or PE

Armoured:Galvanized steel tape,Galvanized steel wire

Outer Sheath:PVC or PE

NO. of cable cross: 1 core(Single core),2cores(Double cores),3cores, 4cores(4 equal-section-area cores OR 3 equal-section-area+1 small section area neutral core),5cores(5 3 equal-section-area cores+2 small area neutral cores OR 4 equal-section-area +1 small area neutral cores).We provide armored type and non-armored type for the cables stated above.

Also can do according to the customer’s request.

4. Characters of XLPE Cable:

a.Max  Long-time operating temperature of XLPE insulated cable is 90°C

b.Installing temperature of cable should not be less than 0°C

c.Max short-circuit temperature is not exceed 250°C,Not more than5 Sec.

d.Unable be laid without the limit of fall with enough mechanical pull,Single core cable can not be laid in iron tube or fixed by circled iron tools around cables

5. Description & Application of XLPE Cable:

Construction

5. packing




6. Advantage:

a. Excellent electric and mechanical characteristics

b. Best Resistance chemical corrosion and heat-ageing,environment stress and flame-retardant

c. Simple in structure,Convenient to use

d. Reduce costs.

British Standard MV cables Voltage Rating

BS6622 – standard British MV cable 6.35/11kV 19/33kV

BS7835 – LSZH British MV cable 6.35/11kV 19/33kV

European standard MV cables Voltage Rating

N2XSY – single copper core XLPE insulated with PVC oversheath 6/10kV 12/20kV 18/30kV

N2XS2Y – single copper core XLPE insulated with PE oversheath 6/10kV 12/20kV 18/30kV

NA2XSY – single aluminium core XLPE insulated with PVC oversheath 6/10kV 12/20kV 18/30kV

NA2XS2Y – single aluminium core XLPE insulated with PE oversheath 6/10kV 12/20kV 18/30kV

N2XSEY – 3 copper core XLPE insulated with PVC oversheath 6/10kV

N2XS(F)2Y – single copper core XLPE insulated with water blocking powder and PE oversheath 6/10kV 12/20kV 18/30kV

N2XS(FL)2Y – single copper core XLPE insulated with water blocking powder and aluminium tape tightly bonded to PE sheath 6/10kV 12/20kV

NA2XS(F)2Y – single aluminium core XLPE insulated with water blocking powder and PE oversheath 6/10kV 12/20kV 18/30kV

NA2XS(FL)2Y – single aluminium core XLPE insulated with water blocking powder and aluminium tape tightly bonded to PE sheath 6/10kV 12/20kV 18/30kV


Company Information

Hebei Huatong Wires and Cables Group Co., Ltd was established in 1993, covering an area of  230, 000 square meters. We own more than 420 sets manufacturing equipment and  250 sets of testing equipment or apparatus. Our annual production capacity is 5 billion Yuan.We have 1200 employers, among which 150  are technicians. Based on the scientific management, now we are a comprehensive, large-scale enterprises in wire and cable industry.Voltage up to 35KV, including X L P E power cables,PVC power cables, mining cables, rubber cables for general purpose, Submersible oil pump cables, solar cables, shipboard cables,lead sheath cables, aerial cables, control and instrument cables, special cables etc.Products are exported to USA, Australia, Singapore, Europe, South America, Middle East, Asia, Africa. CNAS accredited national level laboratory.

 UL Certificates

We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. We also  have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,
KEMA, TUV, SABS,PBS,Bureau Veritas, Lloyd,GL,NK,KR certifications.



We have obtained UL certifications for TC cable, DLO cable,RHH/RHW/RHW-2,XHHW/XHHW-2/SIS, THHN,SER/SEU/USE, MV-90/MV-105,MC cable,AC cable,TECK 90,SOOW,Welding cable,Mining cable,type DG,PV cable,Shipboard cable  and so on.


Our Services

1.25 years production experience and 16 years export experience .

2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc
3. OEM service available based on official & legal authorization.
4.Strict quality control system.
5.Rapid delivery and feedback  Faster lead time than our competitors.
6.Excellent quality with reasonable price.
7.Strong technical support (technical data, drawing, etc.)
8.Professional teamwork service for you actively.
9.Stock available, Free sample is available.

FAQ

(1).When can I get the price?

We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price,please call us ortell us in your e-mail so that we will regard your inquiry priority.

(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.

(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express  account or prepay us if you do not have an account.

(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
