6242y Copper Conductor PVC Insulated PVC Sheath Flexible Electric

6242y Copper Conductor PVC Insulated PVC Sheath Flexible Electric image

Get Latest Price Request a quote

Product Details

Model NO.

6242Y

Insualted

PVC

Color

Red,Blue,White,Black,Green/Yellow and So on

Certificate

CCC,ISO,CE.

Transport Package

Soft Packing in Coil,100m/Roll,or as Your Requests

Specification

IE60227

Trademark

RNE DA

Origin

Hebei, China

HS Code

85444921

Production Capacity

1000roll/Week

Product Description

Copper Conductor PVC Insulated PVC Sheath Flexible Electric Wire Price

Application

PVC insulated wire&cable is suitable for laying at the fixed places. It is widely used in connecting of power device, lighting, daily electrical appliance, instrument etc. with AC rated voltage up to and including450/750V.

Standard

The product implement the standards GB/T5023, equivalent to IEC60227. And it can also be made complying with ASTM, DIN, BS standards etc. In addition, we can design and manufacture the products as the requirements of customers.

Brief construction

1) Conductor:flexible copper wire, Class 6

2) Insulation: PVC

3)Sheath:PVC

4) Other special characteristics: Design and manufacture according to the requirements of customers.

Service performance

1) Rated voltage: 300/500V

2) Long-term working temperature: not be higher than 70°C

3) When laying the cable, the ambient temperature should not lower than 0°C

4) Minimum bending radius: Bending radius≥4D as cable overall diameter≤25mm; Bending radius≥6D as cable overall diameter>25mm.

Specification of pvc insulated flexible cable:

PVC INSULATED FLEXIBLE ROUND MULTI-CORE CABLE
	SIZE/MM2	STRUCTURE/MM	OVERALLDIAMETER/MM
2CORE	0.75	24X0.2	7.6
	1	32X0.2	7.8
	1.5	30X0.25	8.8
	2.5	49X0.25	11
3CORE	0.75	24X0.2	8
	1	32X0.2	8.4
	1.5	30X0.25	9.6
	2.5	49X0.25	11.5
	4	56X0.3	12.5
	6	84X0.3	13.5
	10	126X0.32	16.5
	16	126X0.4	20
	25	196X0.4	30.25
4CORE	0.75	24X0.2	8.6
	1	32X0.2	9.2
	1.5	30X0.25	11
	2.5	49X0.25	12.5
	4	56X0.3	13
	6	84X0.3	15.8
	10	126X0.32	17.6
	16	126X0.4	21.5
	25	196X0.4	33.5
5CORE	0.75	24X0.2	9.4
	1	32X0.2	11
	1.5	30X0.25	12
	2.5	49X0.25	13.5
	4	56X0.3	14.5
	6	84X0.3	16.4
	10	126X0.32	20.1
	16	126X0.4	24.5
	25	196X0.4	37

We are China 6242y Copper Conductor PVC Insulated PVC Sheath Flexible Electric manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
