600V1212AWG+114AWG 2512AWG+114AWG Cu/XLPE/PVC/Aia/PVC Teck90 Teck 90 Copper Control Cable

600V12*12AWG+1*14AWG 25*12AWG+1*14AWG Cu/XLPE/PVC/Aia/PVC Teck90 Teck 90 Copper Control Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Teck 90 control cable

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Certification

ISO9001, RoHS

Brand

Huadong

Rated Voltage

600V

Core

2-37 Cores or Customize

Standard

CSA Std. C22.2

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

600V12*12AWG+1*14AWG 25*12AWG+1*14AWG CU/XLPE/PVC/AIA/PVC Teck90 Teck 90 Copper Control Cable

APPLICATIONS:
Suitable for exposed and concealed wiring in dry, damp or wet locations, for use in ventilated, non-ventilated and ladder-type cable trays in dry, damp or wet locations, for direct earth burial, also for wiring in all hazardous locations when used with certified HL cable fittings.

CONSTRUCTION:
Stranded copper conductors, XLPE (Cross-Linked Polyethylene) insulated, Method 1 – Table E1 or E2 color-coded or Method 4 phase-identified conductors cabled with suitable fillers as necessary, inner PVC (Polyvinyl Chloride) jacket, aluminum interlocked armor, black PVC jacket overall, surface printed.

STANDARDS:

Conductors conform to ASTM B3 & B 8.

Insulation conforms to UL Standard 44, and is approved as Type XHHW-2.

TECK-90/HL Type per CSA Std. C22.2.

Overall jacket approved as Sunlight Resistant and “For CT Use.”

Cables designed to pass the IEEE-383 and IEEE-1202 tests.

Cables meet requirements of ICEA S-95-658/NEMA WC70.

Cable Parameter:

NO.OF COND.	14 AWG – STRANDED			12 AWG – STRANDED			10 AWG – STRANDED
NO.OF COND.	BASIC CAT.NO.	O.D.OVER PVCJKT. in.	WEIGHT lbs/mft	BASIC CAT.NO.	O.D.OVER PVCJKT. in.	WEIGHT lbs/mft	BASIC CAT.NO.	O.D.OVER PVCJKT. in.	WEIGHT lbs/mft
2	9-102	0.67	195	9-202	0.7	228	9-302	0.75	275
3	9-103	0.69	226	9-203	0.73	254	9-303	0.78	327
4	9-104	0.72	256	9-204	0.77	293	9-304	0.83	413
5	9-105	0.76	290	9-205	0.81	350	9-305	0.91	473
7	9-107	0.82	338	9-207	0.91	443	9-307	0.99	552
9	9-109	0.93	420	9-209	0.99	624	9-309	1.09	720
12	9-112	0.99	511	9-212	1.1	653	9-312	1.23	916
15	9-115	1.04	586	9-215	1.16	757	9-315	1.3	1084
19	9-119	1.12	732	9-219	1.25	890	9-319	1.39	1255
25	9-125	1.3	958	9-225	1.42	1210	9-325	1.55	1612
31	9-131	1.38	1110	9-231	1.51	1375	9-331	1.68	1880
37	9-137	1.44	1320	9-237	1.59	1580	9-337	1.77	2075
