600V XLPE/Aia/PVC Metal Clad Acwu90 Cable
600V XLPE/Aia/PVC Metal Clad Acwu90 Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
|
NO OF COND. |
COND.SIZE
|
Grounding wire size |
Insulation Thickness |
Nominal Diameter( over) mm |
Net weight |
||
|
AWG |
AWG |
(mm) |
Twisted Core |
Armor |
Cable |
KG/KM |
|
|
3 |
6 |
8 |
0.68 |
14.3 |
19.1 |
21.6 |
937.7 |
#6 AWG THRU 750 kcmil XLPE/ALUMINUM ARMOURED/PVC/600 V, (-40°C)
Construction:
Conductor: 8 AWG. Thru 1000 kcmil aluminum (8000 series aluminum) compact class “B” strand
Insulation: Cross-linked Polyethylene (XLPE)
Type RW 90 Colour Coding: Black Bonding Conductor (Ground): Concentrically wrapped bare stranded bare copper conductor
Armour: Aluminum Interlocked Armour (AIA)
Jacket: Low acid gas, flame-retardant, moisture and sunlight resistant Polyvinyl Chloride (PVC), black. Custom colours available upon request
Applications:
For wet and dry locations.
To be used for exposed and concealed wiring or where subject to the weather.
For direct earth burial and service entrance above or below ground.
Used in ventilated, non-ventilated and ladder-type cable trays.
Approved for all hazardous locations as per CEC Part 2018 Section 18, when installed with approved connectors.
Specifications and Compliance:
CSA C22.2 No. 51, Armoured Cables
CSA C22.2 No. 38, Thermoset-insulated wires and cables
CSA C22.2 No. 174, Cables and cable glands for use in hazardous locations
CSA C22.2 No. 2556, FT4 Vertical-Tray Flame Test
Techinical data sheet
|
NO OF COND. |
COND.SIZE
|
Grounding wire size |
Insulation Thickness |
Nominal Diameter( over) mm |
Net weight |
||
|
AWG |
AWG |
(mm) |
Twisted Core |
Armor |
Cable |
KG/KM |
|
|
3 |
6 |
8 |
0.68 |
14.3 |
19.1 |
21.6 |
937.7 |
We are China 600V XLPE/Aia/PVC Metal Clad Acwu90 Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
