600V Copper T90 Conductor Tray Cable Type Tc Tc-Er Cic-Tc Cable

600V Copper T90 Conductor Tray Cable Type Tc Tc-Er Cic-Tc Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Application

Heating

Sheath Material

PVC

Insulation Material

PVC/XLPE

Material Shape

Round Wire

Range of Application

Power and Control Tray

Certification

ISO9001, CCC, RoHS, UL

Brand

UL cUL

Voltage

Low Voltage 600V

Package

Rolls/Reels

Used

Industrial Power or Control Circuits

Color

White/Blue/Red/Black/Brown/Yellow etc

Transport Package

Coils and Drums

Specification

12AWG to 2000KCMIL

Trademark

Renda

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

TYPE CIC-TC/TC-ER POWER CABLE THHN Conductors

Application:

Power, control, signal, communication, and lighting circuits. Suited for use in wet and dry areas, conduits, ducts, troughs,

trays, direct burial, aerial supported by a messenger.

Structure:

1. Conductor: Stranded annealed bare copper

Ground Conductor(Optional): One (1) bare stranded copper conductor

2. Insulation: Cross-linked Polyethylene (XLPE) TYPE XHHW-2

Optional Insulation: PVC+Nylon(THHN)

3. Shielding(Optional): Copper Tape Shielding(CTS, Overlap @20%)

4. Outer Jacket: Flame-retardant, and sunlight resistant Polyvinyl Chloride (PVC), Black

Optional Jacket: Low Smoke Zero Halogen (LSZH), Black

Standard:

UL1277

UL File No.:

E468830

Voltage:

600V

Working temperature:

Up to 90°C.

Performance:

VW-1 Flame retardant;

UV resistant.

Cable Parameters

Type	Number of Conductors /size			PVC insulated	Jacket Thickness	Overall Diameter	Approximate Weight
Type	n	*	AWG	mm	mm	mm	kg/km
TC-THHN	2	*	14AWG	0.38	1.14	8.5	102
TC-THHN	3	*	14AWG	0.38	1.14	9.0	130
TC-THHN	4	*	14AWG	0.38	1.14	9.7	161
TC-THHN	5	*	14AWG	0.38	1.14	10.5	193
TC-THHN	6	*	14AWG	0.38	1.14	11.3	226
TC-THHN	7	*	14AWG	0.38	1.14	11.3	249
TC-THHN	9	*	14AWG	0.38	1.52	14.9	360
TC-THHN	10	*	14AWG	0.38	1.52	14.9	382
TC-THHN	12	*	14AWG	0.38	1.52	15.4	435
TC-THHN	15	*	14AWG	0.38	1.52	16.9	530
TC-THHN	16	*	14AWG	0.38	1.52	16.9	553
TC-THHN	19	*	14AWG	0.38	1.52	17.7	636
TC-THHN	20	*	14AWG	0.38	1.52	18.7	677
TC-THHN	25	*	14AWG	0.38	1.52	20.6	829
TC-THHN	30	*	14AWG	0.38	2.03	22.7	1020
TC-THHN	37	*	14AWG	0.38	2.03	24.4	1219

We are China 600V Copper T90 Conductor Tray Cable Type Tc Tc-Er Cic-Tc Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
