600V Ccw Type Mc-Hl W/ Ground Aluminum Alloy Sheath Armor Continuously Corrugated Welded Cable

600V Ccw Type Mc-Hl W/ Ground Aluminum Alloy Sheath Armor Continuously Corrugated Welded Cable image

Get Latest Price Request a quote

Product Details

Model NO.

CCW

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper Conductor

Certification

RoHS

Brand

Huadong

Rated Voltage

600V

Size

8 6 10 12 14 16 18 AWG Ect

Standard

ASTM/UL

Sample

Available

Pairs

3 4 Cores

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

600V CCW Type MC-HL w/ Ground Aluminum Alloy Sheath Armor Continuously Corrugated Welded Cable

APPLICATIONS:
Designed for use on power or control circuits
Can be installed in cable tray, wire ways, racks, or buried directly
This cable has three symmetrically placed grounds to reduce problems associated with pulse-width modulated AC drives
Suitable for VFD applications
Suitable for exposure to hazardous locations, Type MC-HL for
Classes I, II, and III Division 1 and 2

STANDARDS:
• UL 44, XHHW-2
• UL 1309 Marine Shipboard
• UL 1569 Type MC and UL 2225 Type MC-HL
• UL 1581 Designated Type MC as per NEC Article 334 IEEE 1202 available upon request

Construction
Category Conductor Description	Bare annealed copper per ASTM B-3 10 AWG and smaller are compressed Class B stranding per ASTM B8 8 AWG and larger are compact stranding per ASTM B496
Category Insulation Description	Cross-linked Polyethylene (XLPE) type XHHW per UL 44
Ground	Class B stranded bare copper per ASTM B3 and B8 Sized in accordance with NEC Table 250.122
Armor	Impervious, continuously welded and corrugated aluminum alloy sheath
Outer Jacket	Black, Polyvinyl Chloride (PVC), sunlight and oil resistant, per UL 1569, 90°C temperature rating

CABLE PARAMETERS:
For other sizes,pls contact us!

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China 600V Ccw Type Mc-Hl W/ Ground Aluminum Alloy Sheath Armor Continuously Corrugated Welded Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
