4X1.5 4X2.5 4X4 4X6 4X10 4X16 4X25 4X35 4X50 4X95 4X120 mm2 Rubber Sheathed Nsstou Nshtou Mining Reel Crane Festoon Cable

4X1.5 4X2.5 4X4 4X6 4X10 4X16 4X25 4X35 4X50 4X95 4X120 mm2 Rubber Sheathed Nsstou Nshtou Mining Reel Crane Festoon Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Mining Cable

Insulation Material

EPDM/Epr

Sheath Material

CPE/Pcp

Material Shape

Round Wire

Wire Core Material

Stranded Copper

Certification

ISO, CCC, CE, VDE

Model

Ycw

Brand

Huadong

Rated Voltage

0.38/0.66kv 0.66/1.14kv 1.9/3.3kv 3.6/6kv 6/10kv

Cross Section

10mm2-240mm2

Temperature

-20 to +55 Degree

Standards

Mt818, AS/NZS 1802, Icea S-75-381, Sans 1411-3/1520-1

Type

Mc Mcp Mcptj My Myptj Ect

Sample

Available

Color

Black or Others

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

600/1000V Copper Conductor EPR Flexible Rubber NSHTOU Reeling Festoon Cable

APPLICATION

For use in hoists, transporting machines and conveyors, in power chains, as drum and drag cables and as hawsers. Wherever cables are reeled, unreeled, guided by roller trains or similar. Oil and UV resistant to BS EN/IEC 60811-2-1.

CONSTRUCTION

Conductor	Flexible Class 5 tinned copper conductor
Insulation	Rubber compound Type 3GI3 according to VDE 0207 part 20
Filler	EPR (Ethylene Propylene Rubber) Type 3GI3, on a textile polyester support
Bedding	Rubber compound Type GM1b according to VDE 0207 part 21
Braiding	Polyester braid
Sheath	Rubber compound Type 5GM3 according to VDE 0207 part 21

CHARACTERISTICS

Voltage rating (Uo/U) 600/1000V

Temperature Rating

Fixed: -40°C to +60°C

Flexed: -25°C to +60°C

Minimum Bending Radius

Fixed: 4 x overall diameter

Flexed: 5 x overall diameter

Core Identification

NSHTÖU-J

4 core: Green/Yellow Black Grey Brown

5 core: Green/Yellow Black Blue Brown Grey Other sizes available.

NSHTÖU-O

4 core: Grey Brown Black Blue

5 core: Grey Brown Black Blue Black Sheath Colour Black

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

1.what is our payment term ?

Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

The lead time usually is 10 – 30 working days.

3.what is the package of the cable ?

The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

Sure, we provide the free sample for customer to checking.

We are China 4X1.5 4X2.5 4X4 4X6 4X10 4X16 4X25 4X35 4X50 4X95 4X120 mm2 Rubber Sheathed Nsstou Nshtou Mining Reel Crane Festoon Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
