450V Qwpk Flexible Rubber Cable for Harsh Conditions

450V Qwpk Flexible Rubber Cable for Harsh Conditions image

Get Latest Price Request a quote

Product Details

Model NO.

QWPK

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Round Wire

Wire Core Material

Flexible Copper

Certification

ISO, CCC, CE, VDE

Model

Ycw

Brand

Huadong

Product Name

Qwpk Flexible Rubber Cable

Rated Voltage

450V

Cross Section Size

0.75mm2 1mm2 1.5mm2,2.5mm2

Cores

2 3 4 5 Core

Temperature

-20°c to +90°c

Warranty

100% Qualified

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

QWPK Flexible Rubber Cable

QWPK 300 V is a flexible cable for harsh conditions.The cable is mainly used in workshops and garages,on construction sites,and as a tool-connection cable.The cable is also suitable for use in the ground (ground spots), in water, for submersible pumps,and as an extension cable.The cable is mainly used in OEM, road construction

infrastructure,and for temporary or mobile installations.

The polyurethane(PUR)outer sheath guarantees strong mechanical properties and along service life,even in harsh conditions.The ribbed sheath reduces frictional resistance when being dragged over a surface. It can also be used outdoors thanks toits UV resistance.The cable is also water and cold resistant. Installation is easy and the cable can be rolled on as pool thanks the very flexible conductor (Class 5).The cable is halogen-free and limits damage caused by smoke and gases in case of fire.

CONSTRUCTION
Conductor material Copper
Conductor surface Tinned
Core insulation material EPR rubber
Core identification (acc. HD 308 S2) Yes
Material outer sheath Polyurethane(PUR)

CHARACTERISTICS
Max.conductor temperature[°C] 90
Permitted cable outer temperature after assembling without vibration (min) [°C] -40
Permitted cable outer temperature during assembling/handling (min) [°C] -40
Halogen free acc. IEC/EN 60754-1/2
Halogen free(acc. IEC 60754-2) Yes

Basic construction	Nominal outer diameter [mm]	Cable weight [kg/km]	Conductor resistance at 20°C [Ohm/km]	Current carrying capacity in air [A]
2X1.5	8.6	106	13.7	22
2X2.5	10.1	152	8.21	35
3G1.5	9.1	124	13.7	22
3G2.5	10.7	180	8.21	35
3G4	12.5	258	5.09	48
4G1.5	10.1	153	13.7	19
4G2.5	11.9	222	8.21	31
4G4	13.8	321	5.09	41
5G1.5	11	182	13.7	19
5G2.5	13.2	277	8.21	31
5G4	15.4	389	5.09	41
5G6	17.2	519	3.39	50

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced 20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers.We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.
