450/750V 300/500V Water Yz 2*4 Sheathed Waterproof Submersible Pump Flat Rubber Cable

450/750V 300/500V Water Yz 2*4 Sheathed Waterproof Submersible Pump Flat Rubber Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Submersible cable-2

Current

DC & AC

Insulation Material

Rubber

Sheath Material

Rubber

Material Shape

Flat Wire

Wire Core Material

Bare Copper Wire

Certification

VDE, JIS

Model

Brand

Huadong

Rated Voltage

450/750V

Core

3 4 5 Ect

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

Heavy duty 3 4 cores Submersible Water Pump Cable for drinking water (flat type)

Applications
These cables are designed for making connections to submersible pumps in drinking water. It can also be used in industrial water
Dry or damp rooms, as well as outdoors and in industrial water
For connecting mobile, electrical equipment in industrial water
For use with submersible pumps
Submersion acc. AD8 standard down to 10 m depth

Construction

Conductor: Bare copper stranded class 5 to VDE0295, IEC 60228

Insulation: HEPR or XLPE

Outer Sheath: EPR type 3GM2, coloured blue.

Technical data

Test Voltage 50Hz, 5 min: 2500V

Rated Voltage: 450/750V

Maximum admissible conductor Temperature in Operation: 90°C

Short Circuit Temperature: 250°C

Temperature Range:-40°C~+60°

NO. OF CORES X CROSS	OUTER DIAMETER APPROX MM X MM	NET WEIGHT KG/KM
3×1.5	12.4×5.7	100
3×2.5	14.2×6.7	170
3×4	16.6×7.9	240
3×6	18.4×8.5	300
3×10	21.4×9.5	450
3×16	25.9×11.5	680
3×25	30.7×13.1	950
3×35	35.2×15.0	1300
3×50	40.9×17.3	1800
3×70	47.9×19.8	2450
3×95	53.6×22.6	3150
4G1.5	15.4×5.9	140
4×2.5	17.6×6.7	200
4G4	20.6×7.9	290
4G6	23.3×8.5	380
4G10	27.3×9.5	580
4G16	32.7×11.5	880
4G25	39.1×13.1	1260
4G35	45.6×15.0	1700
4G50	52.0×17.3	2360
4G70	61.2×19.8	3250
4G95	69.6×22.6	4150
