450/750V 2.5mm2 4.0mm2 6.0mm2 Nya Strand Copper Conductor PVC Insulated Electric Wires

450/750V 2.5mm2 4.0mm2 6.0mm2 Nya Strand Copper Conductor PVC Insulated Electric Wires image

Get Latest Price Request a quote

Product Details

Model NO.

NYA BV

Application

Indoor, Construction, Building

Conductor Material

Copper

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC

Brand

Rne Da

Voltage

300/500V or 450/750V

Cross Section

0.5mm2-240mm2

Insualted

PVC

Color

Red,Blue,White,Black,Green/Yellow and So on

Certificate

CCC,ISO,CE.

Transport Package

Soft Packing in Coil,100m/Roll,or as Your Requests

Specification

IE60227

Trademark

RNE DA

Origin

Hebei, China

HS Code

85444921

Production Capacity

1000roll/Week

Product Description

450/750V Nya Strand Copper Conductor PVC insulated electric wires

1. Code 227IEC01(BV)

2. Application

PVC insulated wires is suitable for laying at the fixed places. It is widely used in connecting of power device, lighting, daily electrical appliance, instrument etc. with AC rated voltage up to and including 450/750V(U0/U).

3. Standard

The product implement the standards GB/T5023, equivalent to IEC60227. And it can also be made complying with ASTM, DIN, BS standards etc. In addition, we can design and manufacture the products as the requirements of customers.

4. Brief construction

1) Conductor: Copper or aluminium, Solid

2) Insulation: PVC

3) Number of cores: Single core

4) Other special characteristics: Design and manufacture according to the requirements of customers.

5. Service performance

1) Rated voltage: 450/750V

2) Long-term working temperature: not be higher than 70°C

3) When laying the cable, the ambient temperature should not lower than 0°C

4) Minimum bending radius: Bending radius≥4D as cable overall diameter≤25mm; Bending radius≥6D as cable overall diameter>25mm.

6 Specification and technical data

Nominal section (mm2)	Number/diameter of core (mm)	Maximum outer diameter (mm2)	Reference weight (Kg/km)		Conductor resistance at 20°C ≤(Ω/km)
Nominal section (mm2)	Number/diameter of core (mm)	Maximum outer diameter (mm2)	copper	aluminum	aluminum	copper
1.5(A)	1/1.38	3.3	20.3	—–	—–	12.1
1.5(B)	7/0.52	3.5	21.6	—–	—–	12.1
2.5(A)	1/1.78	3.9	31.6	17	11.80	7.41
2.5(B)	7/0.68	4.2	34.8	—–	—–	7.41
4(A)	1/2.25	4.4	47.1	22	7.39	4.61
4(B)	7/0.85	4.8	50.3	——	—–	4.61
6(A)	1/2.76	4.9	65	29	4.91	3.08
6(B)	7/1.04	5.4	71.2	—-	—-	3.08
10	7/1.35	7.0	119	62	3.08	1.83
16	7/1.70	8.0	179	78	1.91	1.15
25	7/2.04	10.0	281	118	1.20	0.727
35	7/2.52	11.5	381	156	0.868	0.524
50	19/1.78	13.0	521	215	0.641	0.387
70	19/2.14	15.0	734	282	0.443	0.268
95	19/2.52	17.5	962	385	0.320	0.193
120	37/2.03	19.0	1180	431	0.253	0.153
150	37/2.25	21.0	1470	539	0.206	0.124
185	37/2.52	23.5	1810	666	0.164	0.0991
240	61/2.25	26.5	2350	857	0.125	0.0754

We are China 450/750V 2.5mm2 4.0mm2 6.0mm2 Nya Strand Copper Conductor PVC Insulated Electric Wires manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
