3X2X0.8 6X2X0.8 2X2X0.8 Liycy Tcwb Screened Tp (Twisted Pair) PVC Control Cable

3X2X0.8 6X2X0.8 2X2X0.8 Liycy Tcwb Screened Tp (Twisted Pair) PVC Control Cable image

Get Latest Price Request a quote

Product Details

Model NO.

LIYCY-TP

Application

Heating, Industrial

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

VDE, EU/IEC

Brand

Huadong

Rated Voltage

300/500V

Pairs

2 3 4 5 6 8 10 12 16

Standard

IEC/En 60332-1-2

Sample

Available

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

LiYCY Cables

Application:
LiYCY cables are flexible multicore flame retardant screened signal and data transmission cables designed for indoor applications with increased requirements for electromagnetic compatibility such as process control units and computer systems.
There are two variants of LiYCY, one of which has twisted pairs (TP) for reduced interference (crosstalk).
LIYCY (TP) :To be installed in dry and humid rooms and used as a termination and connection cable in the control, measuring and signal technology.(left picture bellow)
LiYCY cable can be used for signal transmission between electronic devices, in computer systems or process control units with increased electromagnetic compatibility requirements.(Right picture bellow)

Construction:

VOLTAGE	Up to 0.14mm2: 350V
VOLTAGE	Above 0.14mm2: 500V
CONDUCTOR	Class 5 Flexible Stranded Copper
INSULATION	PVC (Polyvinyl Chloride)
SEPARATOR	Plastic Foil Tape
SCREEN	TCWB (Tinned Copper Wire Braid)
OUTER SHEATH	PVC (Polyvinyl Chloride)

Cable Parameter (LIYCY TP)

NO. OF PAIRS	NOMINAL CROSS SECTIONAL AREA mm2	CONDUCTOR CONSTRUCTION		CONDUCTOR LOOP RESISTANCE ohms/km	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
		No. of strands	Strand Diameter mm
2	0.14	18	0.1	276	5.8	34
2	0.25	14	0.16	151	6.6	46
2	0.34	19	0.16	115	7.5	64
2	0.5	16	0.21	75.6	8.2	75
2	0.75	24	0.21	50.6	8.6	106
3	0.14	18	0.1	276	6.2	43
3	0.25	14	0.16	151	7	64
3	0.34	19	0.16	115	7.9	86
3	0.5	16	0.21	75.6	8.7	98
3	0.75	24	0.21	50.6	9.5	140
4	0.14	18	0.1	276	6.8	50
4	0.25	14	0.16	151	7.6	73
4	0.34	19	0.16	115	8.5	113
4	0.5	16	0.21	75.6	9.3	123
4	0.75	24	0.21	50.6	10.8	179
5	0.14	18	0.1	276	7.7	70
5	0.25	14	0.16	151	8.4	88
6	0.14	18	0.1	276	7.9	81
6	0.25	14	0.16	151	8.6	98
6	0.5	16	0.21	75.6	10.8	162
6	0.75	24	0.21	50.6	12.5	246
8	0.14	18	0.1	276	8.6	93
8	0.25	14	0.16	151	9.4	118
8	0.5	16	0.21	75.6	11.8	190
8	0.75	24	0.21	50.6	14.6	300
10	0.14	18	0.1	276	9.5	115
10	0.25	14	0.16	151	10.7	165
12	0.14	18	0.1	276	9.9	125
12	0.5	16	0.21	75.6	14	342
12	0.75	24	0.21	50.6	17.8	433
16	0.14	18	0.1	276	11.2	148
16	0.75	24	0.21	50.6	18.7	564
