3G 4G 5g Telecommunication Equipment Tfl 4923xx UL Listed Rru DC Power Cable

3G 4G 5g Telecommunication Equipment Tfl 4923xx UL Listed Rru DC Power Cable image

Get Latest Price Request a quote

Product Details

Application

Underground

Conductor Material

Tinned Copper

Sheath Material

Flame Retardant Polyolefin

Insulation Material

Flame Retardant Polyolefin

Material Shape

Flat Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC, RoHS, VDE, cUL

Brand

Zenda

Transport Package

Wooden Drum

Specification

TFL4923XX

Trademark

HT Cables

Origin

China

HS Code

8544492100

Production Capacity

200000/Week

Product Description

3G 4G 5G Telecommunication Equipment TFL 4923xx UL Listed RRU DC Power Cable

Rated 75 or 90ºC dry, optionally 60, 75 or 90 ºC wet, 600V

Application

Halogen free, flexible connecting cable for fixed installation. Intended for power supply of telecom equipment, where there are requirements for low inductance and good temperature resistance. Grey jacket for indoor use. Black jacket is sunlight resistant, UV stabilized, for outdoor use.

Structure

Conductor

Stranded, tinned, annealed copper, IEC 60228 class 5. Three parallel cores to form a flat conductor.

Insulation

Flame retardant polyolefin black and grey.

Shield

Inner: aluminum polyester shield 100% coverage

Outer: Tinned copper Clad aluminum or tinned copper wire braid

Sheath

Flame retardant polyolefin , grey or black

Operating voltage

Max. 90 ºC,dry

Fire resistance

IEC 60332-3 cat C

UL 1685, Vertical tray

Standard:

UL2731, Telecommunication Central Office Power, Battery, and Distribution Cables

Technical data

Model	Conductors x size	Approx. Height x width	Weight Kg/100m		Max. DC resistance at 20ºC
Model	(mm2)	mm	With tinned copper wire braid	With tinned copper clad aluminium alloy braid	Ω/km
TFL 492322	2X2.5mm2(14AWG)	7.3*7.0	10	9.7	8.21
TFL 492324	2X6mm2(10AWG)	9.5*9.5	19.3	18.5	3.39
TFL 492324/0	2X6mm2(10AWG)	9.5*9.5	19.3	18.5	3.39
TFL 492325	2X10mm2 (8AWG)	10.5*11.5	29.2	27.9	1.95
TFL 492325/0	2X10mm2 (8AWG)	10.5*11.5	29.2	27.9	1.95
TFL 492326/0	2X16mm2 (6AWG)	11.8*13.6	42.2	40.8	1.24

We are China 3G 4G 5g Telecommunication Equipment Tfl 4923xx UL Listed Rru DC Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
