35kv 133% LLDPE Jacket Concentric Neutral Mv-90 Cable

35kv 133% LLDPE Jacket Concentric Neutral Mv-90 Cable image

Get Latest Price Request a quote

Product Details

Model NO.

mv power cable

Application

Heating, Building

Conductor Material

Copper or Aluminum

Sheath Material

PVC

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Conduit or Recognized Raceways for Services

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Huatong

Voltage

15kv-35kv

Shield

Copper Wire or Copper Tape

Transport Package

Coils and Drums

Specification

8 AWG--1000 Kcmil

Trademark

Renda

Origin

China

HS Code

8544492100

Production Capacity

200000m/Month

Product Description

15KV Copper Wire XLPE MV90 Cable

1. Main Application
URD – TRXLPEMLPE insulated cables are designed and manufactured to meet the applications of primary underground distribution suitable for use in wet or dry location, direct burial, underground duct, and exposed to sunlight, To be used at 15kV upto 35kV at conductor temperatures not to exceed 90 deg. C for normal operation.

2. SPECIFICATIONS
TRXLPEMLP insulated URD cables meets or exceeds all applicable requirements of thefollowing standards, and guaranteed all cables manufactured and tested under this standards.
– ANSIIICEA S94-649
– AEIC CS-8
– ASTM B-3, ASTM B-8, ASTM B-230 & ASTM B-231

3.CONSTRUCTION
Conductor : Bare aluminium or copper, stranded class B compressed stranding
Conductor Shield :Extruded semi-conducting compound
Insulation : TRXLPE (TreeRetardant XLPE) or XLPE
Insulation Shield : Extruded semi-conducting compound
Concentric Neutral : Uncoated copper concentric neutral wires (coated copper are optional)
Encapsulated Jacket : Non-conducting LLDPE embedded jacket with extruded red stripes.
PVC or Semi-conducting jacket are available upon request

Data sheet:

Condctor		Copper Neutral (1/3)		diameter(inch)
AWG orMCM	Stranding	Number of Wires	Size AWG (Solid)	Conductor	Over	Over Insul.	Over Neutral	Over
AWG orMCM	Stranding	Number of Wires	Size AWG (Solid)	Conductor	Insulation	Shield	Wires	Encaps. Jkt.
1/0	19 wire	9	14	0.37	1.12	1.23	1.35	1.46
2/0	19 wire	11	14	0.42	1.17	1.27	1.40	1.50
3/0	19 wire	14	14	0.47	1.22	1.32	1.48	1.59
4/0	19 wire	11	12	0.53	1.28	1.38	1.54	1.71
250	37 wire	13	12	0.57	1.33	1.44	1.64	1.81
350	37 wire	12	10	0.68	1.44	1.54	1.70	1.89
500	37 wire	17	10	0.81	1.57	1.72	1.88	2.04
750	61 wire	25	10	0.99	1.76	1.93	2.11	2.28
1000	61 wire	33	10	1.14	1.92	2.06	2.27	2.43

We are China 35kv 133% LLDPE Jacket Concentric Neutral Mv-90 Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
