300V Non-Metallic Sheathed Nmd90 14/2 8/3 Wire Nmwu 4/2 Canadian Standard Building Wires

300V Non-Metallic Sheathed Nmd90 14/2 8/3 Wire Nmwu 4/2 Canadian Standard Building Wires image

Get Latest Price Request a quote

Product Details

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Flat Wire

Certification

ISO9001, CE, CCC, RoHS, VDE

Jacket

PVC

Number of Core

2+1 3+1

Voltage

300V

Characteristic

Risistant Oils, Acids

Cross Section

14AWG---2AWG

Color

Requirement

Packing

150meters Coils, 75meters Coil

Conductor

Copper

Qualification

cUL Certificate

Transport Package

150meters Coils, 75meters Coil

Specification

14/2 14/3 12/2 12/3 10/2 6/3

Trademark

RNEDA

Origin

China

HS Code

8544492100

Production Capacity

10000m/Month

Product Description

300V Non-Metallic Sheathed Nmd90 14/2 8/3 Wire nmwu 4/2 canadian standard building wires

1. Application

MD90 cables may be used for both exposed work in dry locations or concealed work in dry or damp locations.

The maximum allowable conductor temperature is 90°C. The minimum recommended installation temperature is -25°C for two-conductor cables and -10°C for three-conductor cables (with suitable handling procedures). Material should be properly stored above 0°C for 24 hours prior to installation.

PVC / NYLON INSULATION

PVC JACKET

GROUND CONDUCTOR COPPER CONDUCTOR PVC / NYLON INSULATION

PVC JACKET

Conductor			Insulation		Ground		Approx. Jacket thickness		Approx. Cable Dia.		Approx. Cable weight		Allowable Ampacities 30°C
Size (AWG)	Cores	Strands	Inches	mm	Size (AWG)	Core	Inches	mm	Inches	mm	Ib/ 1000ft	Kg/ km
14	2	1	0.034	0.86	14	1	0.030	0.76	0.388*0.192	9.86*4.88	68	101	25*
14	2	1	0.034	0.86	14	1	0.030	0.76	0.388 x 0.192	9.86 x 4.88	68	101	25*
12	2	1	0.034	0.86	14	1	0.030	0.76	0.422 x 0.209	10.71 x 5.30	86	129	30*
10	2	1	0.034	0.86	12	1	0.030	0.76	0.481 x 0.230	12.21 x 5.84	122	182	40*
8	2	7	0.040	1.02	10	1	0.045	1.14	0.636 x 0.312	16.15 x 7.92	208	310	55
6	2	7	0.051	1.30	8	7	0.045	1.14	0.792 x 0.370	20.12 x 9.40	315	468	75
14	3	1	0.034	0.86	14	1	0.030	0.76	0.345	8.77	86	128	25*
12	3	1	0.034	0.86	14	1	0.030	0.76	0.381	9.69	114	169	30*
10	3	1	0.034	0.86	12	1	0.030	0.76	0.427	10.85	163	242	40*
8	3	7	0.040	1.02	10	1	0.045	1.14	0.570	14.47	275	408	55
6	3	7	0.051	1.30	8	7	0.045	1.14	0.695	17.65	421	627	75
3	3	7	0.051	1.30	6	7	0.080	2.03	0.925	23.48	799	1189	115

1.Packing.

3 Company information.

Hebei huatong wires&cables Group Co.,ltd.It was established in 1993, We are a listed cables company well known as the largest CUL Certifited cable wires manufacturer in China also the largest cable wires exporter in whole China.

We have passed more than 15 kind of CUL listed products in our factory, such as NMD90 wire, RW90, AC90,ACWU90,TECK90,SOOW flexible cord, high voltage cables,mining cables,, we usually ship more than 500 containers to Canadian market every year!

FAQ

(1).When can I get the price?

We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please

call us or tell us in your e-mail so that we will regard your inquiry priority.

(2).How can I get a sample to check your quality?

After price confirmation, you can require for samples to check our quality. Sample is free, but the freight

charge should be paid.

(3).How long can I expect to get the sample?

After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7

days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.

(4).What about the lead time for mass production?

Honestly, it depends on the order quantity and the season you place the order.Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
