300V Flexible Tinned Copper Silicone Rubber 0.5mm 0.75mm 1mm 1.5mm 2.5mm H03s-K High Temperature Cable Wire

300V Flexible Tinned Copper Silicone Rubber 0.5mm 0.75mm 1mm 1.5mm 2.5mm H03s-K High Temperature Cable Wire image

Get Latest Price Request a quote

Product Details

Model NO.

H03S-K

Application

Heating, Electrical Appliances

Conductor Material

Tinned Copper

Sheath Material

Silicone Rubber

Insulation Material

Silicone Rubber

Material Shape

Round Wire

Certification

VDE

Brand

Huadong

Rated Voltage

300/300V

Cores

Single Core

Size

0.5mm to 2.5mm2

MOQ

1000m

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

H03S-K ATC Silicone Rubber Insulated 300/300 V Rated Cable Wire

Application

For wiring at high ambient temperature zones like boiler house, etc.

Electric motor industry.

Air- Conditioning technology.

Furnace construction.

Thermal and heating elements.

Product Construction

Conductor : Annealed Tinned Copper Conductor as per EN 60228,Class 5

Insulation : Elastomeric Compound Type EI 2 (Silicone Rubber)

Colour : Black (or) as per customer order

Technical Data

Specification : BS EN 50525-2-412 2 0.5 mm to 2.5 mm – Class 5

Test voltage : 2000 V

Operating Temperature : -55°C to +180°C

Rated Voltage : 300/300V

Max. Temperature of Short Circuit : 350° C

Min. Insulation Resistance constant at 27°C : 3670 M Ω. km

Features

High temperature – resistant.

Halogen – free.

Cold resistant.

Flame retardant.

Weather resistant.

Size	Conductor Construction No. of Standsx Stand dia Nos x mm (Nom.)	Nominal Insulation Thickness	Overall Diameter		Max. Conductor Resistance at 20ºC	Weight (Approx.)
Size		Nominal Insulation Thickness	Lower Limit	Upper Limit	Max. Conductor Resistance at 20ºC	Weight (Approx.)
mm	mm	mm	mm	mm	Ω/km	Kg/Km
0.5	16×0.20	0.6	2.0	2.7	40.1	9
0.75	24×0.20	0.6	2.1	2.8	26.7	11
1	32×0.20	0.6	2.2	3.0	20.0	14
1.5	30×0.25	0.7	2.8	3.6	13.7	20
2.5	50×0.25	0.8	3.3	4.3	8.21	29

1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.

5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

We are China 300V Flexible Tinned Copper Silicone Rubber 0.5mm 0.75mm 1mm 1.5mm 2.5mm H03s-K High Temperature Cable Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
