300V 14/2 12/2 Nmd90 Cable with cUL Certificate

300V 14/2 12/2 Nmd90 Cable with cUL Certificate image

Get Latest Price Request a quote

Product Details

Model NO.

NMD90 Cable

Application

Building Wire

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Building Wire

Certification

cUL Certificate

Brand

Ren Da

Production Name

Nmd90 Cable

Certificate

cUL

Voltage

300V

Size

14/2 12/2 10/2 8/2

Core

2+1, 3+1

out Sheathed Material

PVC

Outsheathed Color

White, Orange, Red, Black

Transport Package

Standard Export Drum

Specification

14awg 12awg 10awg 8awg 6awg

Trademark

RNE DA

Origin

Tangshan, Hebei Province

HS Code

8544492100

Production Capacity

300km/Month

Product Description

300V 14/2 12/2 flat NMD90 cable with Cul certificate for Canadian market

Applications:

NMD90 cables may be used for both exposed work in dry locations or concealed work in dry or damp locations. The maximum allowable conductor temperature is 90°C. The minimum recommended installation temperature is -25°C for two-conductor cables and -10°C for three-conductor cables (with suitable handling procedures). Material should be properly stored above 0°C for 24 hours prior to installation. The maximum voltage rating for all intended applications is 300 volts. Consult the Canadian Electrical Code1 for further information related to applications

Standards:

• ASTM

• CSA C22.2 No. 48 (non-metallic sheathed cable)

• Canadian Electrical Code

CONSTRUCTION:
Conductors:
Solid 14-10 AWG soft, uncoated copper, per ASTM-B3
Stranded 8 AWG conductor and larger uncoated, copper ASTM-B8
Insulation:
Color-coded Polyvinyl Chloride (PVC) compound meeting the required thickness of Type THHN with a heat-stabilized Nylon jacket rated for 90°C in dry locations.
Grounding Conductor:
Soft, uncoated copper per ASTM-B3 and/or ASTM-B8
Jacket:
A 30-mil, color-coded, PVC jacket is applied over the completed assembly as follows:
14 AWG White I 12 AWG Yellow I 10 AWG Orange I 8 AWG Black I 6 AWG Black

specification.

Size (AWG)	Number of Strands	Ground Wire Size	Insulation Thickness (in)		Allowable Ampacity (Amps)*	Outside Diameter (in)	Approximate Net Weight (lbs/1000 ft)
Size (AWG)	Number of Strands	Ground Wire Size	PVC	Nylon	Allowable Ampacity (Amps)*	Outside Diameter (in)	Approximate Net Weight (lbs/1000 ft)
14/2 G	Solid	14	0.015	0.004	15	0.170 x 0.390	56
12/2 G	Solid	12	0.015	0.004	20	0.160 x 0.450	82
10/2 G	Solid	10	0.020	0.004	30	0.210 x 0.493	123
8/2 G	7	10	0.030	0.005	40	0.290 x 0.580	185
6/2 G	7	10	0.030	0.005	55	0.330 x 0.695	256
14/3 G	Solid	14	0.015	0.004	15	0.170 x 0.450	74
12/3 G	Solid	12	0.015	0.004	20	0.345	107
10/3 G	Solid	10	0.020	0.004	30	0.430	165
8/3 G	7	10	0.030	0.005	40	0.555	251
6/3 G	7	10	0.030	0.005	55	0.612	352
4/3 G	7	8	0.040	0.006	70	0.820	565
2/3 G	7	8	0.040	0.006	95	0.945	841
**14/4 G & 14/2-2 G	Solid	14	0.015	0.004	12	0.345	90
**12/4 G & 12/2-2 G	Solid	12	0.015	0.004	16	0.385	132
**10/4 G	Solid	10	0.020	0.004	30	0.540	205

We are China 300V 14/2 12/2 Nmd90 Cable with cUL Certificate manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
