300/500V YSLTOE YSLTOE-J 36G2.5 container crane control spreader cable
YSLTOE-J Application:
As a control cable, the YSLTOE-J is designed specifically to be integrated with high-speed container cranes using gravity-feed collector buckets. It is also referred to as a spreader cable, and works to control the locking mechanisms of the buckets. It has a rated voltage of 300/500V
Specification
These container cranes are commonly used in opencast mining but variations also operate in ship-to-shore marine loading where they may be more commonly referred to as gantry cranes. As a control cable, it regulates the operation and transmits signal.
The YSLTOE is sheathed with Halogen-free Polyurethane (PUR) to offer robust protection from environmental elements, whilst the construction sees central support fillers of Kevlar and lead rope. It should be noted that whilst the YSLTOE emits no toxic gases in the event of a fire, the PUR remains a flammable material and any use within buildings should be considered.
| VOLTAGE | 300/500V |
| CENTRAL SUPPORT ELEMENT | Lead Balls Ropes Stranded Around, Kevlar Supports |
| CONDUCTOR | Class 5 Flexible Stranded Copper |
| INSULATION | Thermoplastic Compound |
| OUTER SHEATH | Halogen-Free PUR (Polyurethane) |
YSLTOE Cable Sizes
The cable is configured as 6 cores bundles laid up with central lead ball rope, stranded around the central support. As a multicore cable, it is provided in 30G up to 48G cores, in core sizes of 2.5mm2. A 48 core variant is also available in 1mm2 core size
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality.
2) Professional and skillful workers care every details in handling the producing.
3) Quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China 300/500V Ysltoe Ysltoe-J 36g2.5 Container Crane Control Spreader Basket Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
