300/500V Sy PVC Yslysy Steel Wire Braided Armoured Flexible Connecting Control Cable
300/500V Sy PVC Yslysy Steel Wire Braided Armoured Flexible Connecting Control Cable image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Steel wire braided flexible connecting cables for instrumentation and control equipment, for tooling machinery production lines, and in flexible applications for free movement without tensile load. Suitable for use in dry, moist and wet rooms. The galvanised steel wire braid serves as protection against mechanical traverse loads and acts as a magnetic screen against interference. These cables are not used for outdoor or underground installation.
CHARACTERISTICS
Voltage Rating 300/500V
Temperature Rating Fixed: -40°C to +80°C
Fiexed: -15°C to +70°C
Minimum Bending Radius Fixed: 6 x overall diameter
Moved: 15 x overall diameter
CONSTRUCTION
Conductor Class 5 flexible copper conductor
Insulation PVC (Polyvinyl Chloride)
Bedding PVC (Polyvinyl Chloride)
Braiding GSWB (Galvanized Steel Wire Braid)
Sheath PVC (Polyvinyl Chloride)
|
Number of cores and nominal cross section
|
Copper figure
|
Conductor construction
|
Overall diameter
|
Weight
|
|
(appr. value)
|
appr.
|
appr.
|
||
|
mm2
|
kg/km
|
mm
|
mm
|
kg/km
|
|
3 x 0,5
|
43,0
|
16 x 0,21
|
5,9
|
55,0
|
|
4 x 0,5
|
49,0
|
16 x 0,21
|
6,4
|
73,0
|
|
5 x 0,5
|
57,0
|
16 x 0,21
|
7,0
|
91,0
|
|
12 x 0,5
|
104,0
|
16 x 0,21
|
9,8
|
208,0
|
|
25 x 0,5
|
211,0
|
16 x 0,21
|
13,7
|
354,0
|
|
2 x 0,75
|
43,0
|
24 x 0,21
|
6,2
|
56,0
|
|
3 x 0,75
|
52,0
|
24 x 0,21
|
6,5
|
70,0
|
|
4 x 0,75
|
61,0
|
24 x 0,21
|
7,0
|
96,0
|
|
5 x 0,75
|
72,0
|
24 x 0,21
|
7,8
|
157,0
|
|
7 x 0,75
|
89,0
|
24 x 0,21
|
8,4
|
168,0
|
|
10 x 0,75
|
121,0
|
24 x 0,21
|
10,4
|
217,0
|
|
12 x 0,75
|
138,0
|
24 x 0,21
|
10,9
|
231,0
|
|
18 x 0,75
|
211,0
|
24 x 0,21
|
12,8
|
314,0
|
|
25 x 0,75
|
280,0
|
24 x 0,21
|
15,2
|
434,0
|
|
34 x 0,75
|
346,0
|
24 x 0,21
|
17,1
|
529,0
|
|
2 x 1
|
51,0
|
32 x 0,21
|
6,5
|
83,0
|
|
3 x 1
|
62,0
|
32 x 0,21
|
6,7
|
111,0
|
|
4 x 1
|
74,0
|
32 x 0,21
|
7,4
|
131,0
|
|
5 x 1
|
88,0
|
32 x 0,21
|
8,1
|
155,0
|
|
7 x 1
|
112,0
|
32 x 0,21
|
8,8
|
190,0
|
|
12 x 1
|
185,0
|
32 x 0,21
|
11,5
|
286,0
|
|
18 x 1
|
268,0
|
32 x 0,21
|
13,8
|
393,0
|
|
25 x 1
|
354,0
|
32 x 0,21
|
16,0
|
658,0
|
|
34 x 1
|
458,0
|
32 x 0,21
|
18,4
|
759,0
|
|
50 x 1
|
671,0
|
32 x 0,21
|
22,0
|
994,0
|
|
2 x 1,5 *
|
65,0
|
30 x 0,26
|
7,1
|
97,0
|
|
3 x 1,5 *
|
82,0
|
30 x 0,26
|
7,6
|
124,0
|
|
4 x 1,5
|
100,0
|
30 x 0,26
|
8,2
|
166,0
|
|
5 x 1,5
|
119,0
|
30 x 0,26
|
9,0
|
192,0
|
|
7 x 1,5
|
154,0
|
30 x 0,26
|
9,8
|
245,0
|
|
12 x 1,5
|
268,0
|
30 x 0,26
|
13,0
|
365,0
|
|
18 x 1,5
|
373,0
|
30 x 0,26
|
15,5
|
556,0
|
|
25 x 1,5
|
530,0
|
30 x 0,26
|
18,0
|
737,0
|
|
27 x 1,5
|
560,0
|
30 x 0,26
|
20,0
|
750,0
|
|
34 x 1,5
|
686,0
|
30 x 0,26
|
20,9
|
966,0
|
|
50 x 1,5
|
1.001,0
|
30 x 0,26
|
24,8
|
1.342,0
|
|
2 x 2,5
|
92,0
|
50 x 0,26
|
8,5
|
161,0
|
|
3 x 2,5
|
118,0
|
50 x 0,26
|
9,0
|
187,0
|
|
4 x 2,5
|
147,0
|
50 x 0,26
|
9,9
|
241,0
|
|
5 x 2,5
|
176,0
|
50 x 0,26
|
11,0
|
274,0
|
|
7 x 2,5
|
253,0
|
50 x 0,26
|
12,0
|
344,0
|
|
12 x 2,5
|
408,0
|
50 x 0,26
|
15,9
|
407,0
|
|
4 x 4
|
248,0
|
56 x 0,31
|
11,6
|
307,0
|
|
5 x 4
|
288,0
|
50 x 0,26
|
12,8
|
370,0
|
|
2 x 6
|
170,0
|
84 x 0,31
|
12,5
|
180,0
|
|
4 x 6
|
343,0
|
84 x 0,31
|
14,0
|
402,0
|
|
5 x 6
|
403,0
|
84 x 0,31
|
15,5
|
506,0
|
|
4 x 10 *
|
535,0
|
80 x 0,41
|
17,2
|
747,0
|
|
5 x 10
|
635,0
|
80 x 0,41
|
19,3
|
861,0
|
|
4 x 16
|
800,0
|
128 x 0,41
|
20,0
|
1.041,0
|
|
5 x 16
|
960,0
|
128 x 0,41
|
22,2
|
1.289,0
|
|
4 x 25
|
1.280,0
|
200 x 0,41
|
24,7
|
1.460,0
|
|
5 x 25
|
1.530,0
|
200 x 0,41
|
27,5
|
1.840,0
|
1.You are manufacturer or trader ?
We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.
2.How can I get the quotation of the products ?
Pls send inquiry to us,we will reply you within 12 hours.
3.What does your company do regarding quality control?
1) all raw materials we selected are the highest quality.
2) professional and skillful workers care every details in handling the producing.
3) quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.
Our technical engineers can give you the professional suggestions.
5.Can I get the sample?
Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.
We are China 300/500V Sy PVC Yslysy Steel Wire Braided Armoured Flexible Connecting Control Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
